Introduction to WOODWARD 8237-1597
8237-1597 Product Overview
The WOODWARD 8237-1597 is a high-precision digital signal regulator, a key member of the brand’s 8237 series tailored for industrial process control and turbine auxiliary systems. It specializes in converting and conditioning analog control signals, integrating linearization algorithms and anti-interference technology to ensure stable output for critical control loops. Widely applied in power generation, petrochemical, and marine engineering, it processes speed feedback signals for steam turbine lubrication systems, converts pressure signals for oil pipeline compressors, and stabilizes control signals for gas turbine fuel supply modules. Its compact and rugged design features a dust-proof metal housing with industrial-grade EMI shielding, adapting to high-vibration and high-temperature environments in power plant control rooms and offshore platforms. Fully compatible with WOODWARD 505 series controllers and 2301A governors, it supports standard Modbus protocol for seamless integration into DCS systems, enabling real-time signal monitoring and remote parameter adjustment to enhance control loop reliability.
8237-1597 Technical Specifications
-
Product Type: Digital signal regulator (8237 series industrial-grade model)
-
Core Functions: Analog signal conversion & conditioning, PID closed-loop control, anti-interference processing, fault self-diagnosis
-
Application Compatibility: Turbine auxiliary systems, oil pipeline compressors, gas turbine fuel controls, generator set auxiliary loops
-
Input Configuration: 4×4-20mA analog inputs (programmable); 8 discrete contact inputs; dedicated speed signal input
-
Output Configuration: 4×4-20mA analog outputs; 2×0-10V DC auxiliary outputs; 4 relay alarm outputs
-
Control Performance: Signal linearity error ≤±0.1%; response time <20ms; drift ≤0.05%/°C
-
User Interface: 2-line×16-character LCD display; 4 tactile buttons for on-site calibration
-
Communication Interface: RS-485 (Modbus RTU); optional RS-232 for local configuration
-
Power Supply: 24V DC nominal; 18-36V DC wide input range; typical power consumption 12W
-
Operating Environment: Temperature -25°C to +70°C; humidity 0-95% (non-condensing); vibration resistance 5g (10-500Hz)
-
Physical Traits: 145mm×95mm×55mm (L×W×H); weight ~0.8kg; DIN rail mount; IP20 protection (panel-mounted)
-
Certifications: CE, UL certified; complies with IEC 61010-1 industrial measurement standards
Recommended WOODWARD Related Models
-
WOODWARD 505E: Advanced turbine controller that integrates regulator signals for comprehensive steam turbine management.
-
WOODWARD 2301A: Cost-effective speed governor that pairs with the regulator for small generator set control.
-
WOODWARD 9907-164: 505 series turbine governor that uses regulator-processed signals for precise speed control.
-
WOODWARD CPC-II: Current-pressure converter that translates regulator outputs to hydraulic valve control signals.
-
WOODWARD ProTech 203: Turbine protection system that receives fault signals from the regulator for emergency shutdown.
-
WOODWARD Varistroke-DX: Electro-hydraulic actuator that executes control commands from regulator-equipped systems.
-
WOODWARD 2301D-ST: Steam turbine-specific controller that complements the regulator in small steam systems.
-
WOODWARD 8237-2597: Sister model with enhanced output current capacity for heavy-duty industrial loops.
-
WOODWARD Flex500: Multi-turbine control system that centralizes data from multiple 8237 series regulators.
-
WOODWARD 5009 TMR: Triple-redundant controller that uses regulator signals for critical nuclear turbine control.
-
WOODWARD 1712 EPG: All-in-one governing system that integrates regulator functions for small turbomachinery.
-
WOODWARD K-Series Actuators: Electric throttle units that respond to conditioned signals from the regulator.
-
WOODWARD LinkNet-HT: Distributed I/O module that expands the regulator’s signal monitoring range.
-
WOODWARD APECS® 4500: Engine control module that pairs with the regulator for CHP system optimization.
-
WOODWARD 9907-167: Low-temperature turbine controller that works with the regulator in polar applications.
