Introduction to WOODWARD 9907-163
Product Overview
The WOODWARD 9907-163 is a microprocessor-based digital turbine controller, standing as a pivotal component in the brand’s 505 series for steam turbine regulation. It integrates programmable control logic, multi-parameter processing, and user-friendly configuration features to deliver stable speed and load management for single or split-range actuator-equipped turbines. Widely applied in thermal power generation, industrial process drives, and turbogenerator systems, it ensures consistent steam turbine operation in thermal plants, optimizes mechanical drive performance in manufacturing, and maintains reliable output for backup power units. Its robust NEMA 4-compliant enclosure offers excellent protection against dust and water, making it suitable for harsh industrial environments like power plant control rooms and factory workshops. Seamlessly compatible with WOODWARD Varistroke hydraulic actuators and 505 View configuration software, it supports RS-232/RS-422 communication for easy integration into plant control networks, simplifying monitoring and maintenance.
9907-163 Technical Specifications
-
Product Type: Digital steam turbine controller (505 series)
-
Core Functions: Speed/load regulation, start/stop sequence control, parameter monitoring, fault alarming
-
Applicable Turbines: Steam turbines with single or split-range actuators (excluding extraction turbines)
-
Input Configuration: 16 discrete contact inputs; 6 programmable 4-20mA current inputs
-
Output Configuration: 2 actuator outputs; 8 relay outputs; 6 programmable current outputs
-
Control Performance: Enables precise turbine operation; supports load distribution in parallel applications
-
User Interface: 30-key keypad; 2-line×12-character display; on-site programming
-
Communication Ports: RS-232C/RS-422 serial port; compatible with Modbus protocol
-
Power Supply: 18-32V DC; nominal 24V DC
-
Operating Environment: -13°C to +65°C (standard); passes Lloyd’s Type ENV3 dry heat test; 95% RH (non-condensing)
-
Physical Dimensions: 28.1cm×12.7cm×28.1cm (L×W×H); weight ~4.4kg
-
Protection & Certifications: NEMA 4 enclosure; compliant with industrial control safety standards
Recommended WOODWARD Related Models
-
WOODWARD 505XT: Advanced version of 9907-163, designed for extraction and condensing steam turbines
-
WOODWARD Varistroke-DX Skid: Dual redundant hydraulic servo system, pairs with 9907-163 for turbine valve control
-
WOODWARD 505E: Next-gen turbine controller with enhanced Ethernet and OPC UA connectivity
-
WOODWARD 2301E-HT: Specialized controller for Francis hydro turbines, complements 9907-163 in hydropower applications
-
WOODWARD ProTech TPS: Turbine protection system, adds overspeed and overpressure safeguards for 9907-163-based setups
-
WOODWARD Flex500: Programmable control system, integrates 9907-163 logic for multi-turbine coordination
-
WOODWARD MicroNet TMR: Triple-redundant controller, ideal for critical nuclear power turbine applications
-
WOODWARD 1712 EPG: All-in-one governing system with built-in actuator, cost-effective alternative for small turbines
-
WOODWARD APECS® 4000: Engine control module, pairs with 9907-163 in combined heat and power systems
-
WOODWARD DPG 2000: Generator paralleling controller, synchronizes 9907-164-governed turbines with power grids
-
WOODWARD 9907-164: Sister model of 9907-163, optimized for gas turbine and turbogenerator applications
-
WOODWARD K-Series Actuators: Electric throttle units, execute speed control commands from 9907-163
-
WOODWARD 505 HT: Hydro turbine-specific controller, works with 9907-163 in Kaplan and Pelton turbine systems
-
WOODWARD LinkNet-I/O: Distributed I/O module, expands 9907-163’s monitoring and control capabilities
-
WOODWARD 2300E: Compact programmable controller, suitable for small-scale turbine systems paired with 9907-163
