Introduction to WOODWARD 9907-164
Product Overview
The WOODWARD 9907-164 is a high-performance microprocessor-based digital controller, serving as a core component in the brand’s 505 series for industrial turbine and generator control. It integrates advanced adaptive PID algorithms, multi-channel data acquisition, and comprehensive safety mechanisms to deliver precise speed and load regulation for rotating equipment under dynamic working conditions. Widely applied in power generation, oil & gas, and marine engineering, it governs steam and gas turbines in thermal plants to maintain grid frequency stability, controls turbine-driven compressors in oil pipelines for optimal pressure, and manages propulsion systems in offshore platforms. Its rugged design features an IP56-rated aluminum alloy housing, withstanding salt spray, high humidity, and vibrations in harsh industrial environments. Seamlessly compatible with WOODWARD CPC-II electro-hydraulic converters and ProTech protection systems, it supports Modbus and optional Ethernet protocols, enabling smooth integration into DCS/SCADA platforms for remote monitoring and diagnostics.
The WOODWARD 8237-2597 is a versatile digital regulator, serving as a key control component in the brand’s 820 series for industrial automation systems. It integrates multi-algorithm control logic, comprehensive I/O processing, and intuitive operation features to deliver precise parameter regulation for power generation and industrial process control applications. Widely applied in thermal power plants, chemical processing lines, and turbomachinery systems, it stabilizes operational parameters of boiler feedwater pumps, optimizes fuel supply for industrial furnaces, and ensures consistent output of small-scale turbogenerators. Its rugged structural design with dust-proof and water-resistant properties adapts to harsh industrial environments like control rooms and workshop equipment bays. Seamlessly compatible with WOODWARD 2301 series controllers and Varistroke actuators, it supports mainstream communication protocols such as Modbus and Profibus, enabling smooth integration into DCS systems for centralized monitoring and remote diagnostics.
9907-164 Technical Specifications
-
Product Type: Digital turbine & generator controller (505 series core model)
-
Core Functions: Speed/load precision control, critical speed avoidance, automatic start/stop sequence, fault self-diagnosis
-
Application Compatibility: Steam turbines, gas turbines, turbogenerators, oil pipeline compressors
-
Input Configuration: 16 contact inputs (4 dedicated + 12 programmable); 6 programmable 4-20mA current inputs
-
Output Configuration: 0-10V DC analog output; supports single-range/split-range actuator driving
-
Control Performance: Speed regulation accuracy ±0.01%; load step response time <50ms; supports isochronous parallel operation
-
User Interface: 30-key multi-function keyboard; 2-line×24-character display; on-site parameter configuration
-
Communication Ports: RS-232/RS-422 (standard); Ethernet (optional); Modbus protocol support
-
Power Supply: 24V DC (nominal); 18-36V DC wide input range; typical input current 1A
-
Operating Environment: Temperature -20°C to +60°C; humidity 95% RH (non-condensing); vibration resistance 10g (5-2000Hz)
-
Physical Traits: 355.6mm×279.4mm×101.6mm (W×H×D); weight ~4.13kg; IP56 protection rating
-
Certifications: CE, UL certified; meets IEC 60529, ISO 8528-5, and IEC 61508 SIL 3 safety standards
Recommended WOODWARD Related Models
-
WOODWARD 505E: Next-gen turbine controller, upgrades with enhanced Ethernet and OPC UA communication for smart factories
-
WOODWARD CPC-II (9907-1200): Electro-hydraulic converter that translates control signals to turbine valve movements
-
WOODWARD ProTech TPS: Turbine protection system, adds overspeed and overload emergency shutdown safeguards
-
WOODWARD 2301A: Classic analog governor, cost-effective complement for simple speed control scenarios
-
WOODWARD Flex500: Programmable control system, integrates core logic for multi-turbine coordination in large plants
-
WOODWARD LinkNet-HT: Distributed I/O module, expands monitoring and control capabilities for large-scale systems
-
WOODWARD APECS® 4500: Programmable engine controller, ideal for combined heat and power (CHP) systems
-
WOODWARD DPG 2200: Generator load-sharing controller, synchronizes units with power grids for parallel operation
-
WOODWARD 1712 EPG: All-in-one governing system with built-in actuator, suitable for small-scale turbomachinery
-
WOODWARD K-Series Actuators: Electric throttle units that execute speed control commands from the controller
-
WOODWARD MicroNet TMR: Triple-redundant controller, designed for critical applications like nuclear power turbines
-
WOODWARD 9907-165: 110V DC power variant, tailored for high-voltage industrial control panels
-
WOODWARD 2301D-ST: Steam turbine-specific controller, cost-effective option for small steam systems
-
WOODWARD SPC Servo Controller: Precision position controller, enhances valve control accuracy when paired with the system
-
WOODWARD 5009 TMR: High-safety redundant controller, upgrades reliability for emergency turbine systems View more …..
