WOODWARD PEAK150 Digital control module

Woodward Peak150 Digital Control Module Overview

The Woodward Peak150 is a high-performance digital control module designed for precision monitoring and regulation of industrial engines, turbines, and power generation systems. As part of Woodward’s legacy in industrial automation and control solutions, the Peak150 is widely used in applications requiring reliable speed control, load sharing, and process optimization. It is particularly suited for gas turbines, diesel engines, and dual-fuel systems in industries such as power generation, oil and gas, marine, and critical infrastructure.

Key Features

1. Core Functionality
   • Speed and Load Control: Provides precise control of engine/turbine speed and load sharing across multiple units in parallel operation.
   • Process Control: Manages critical parameters such as fuel flow, temperature, pressure, and emissions to ensure system stability and efficiency.
   • Flexible Configuration: Supports both single and dual redundant configurations for mission-critical applications.
2. Technical Specifications
   • Input/Output (I/O):
     • Analog inputs (e.g., 4–20 mA, 0–10 V) for sensors (pressure, temperature, speed).
     • Digital inputs/outputs for status monitoring and actuator control.
     • Pulse inputs for speed sensing (magnetic pickups or proximity probes).
   • Communication Protocols:
     • Built-in support for Modbus RTU/TCP, CANbus, and Ethernet/IP for integration with SCADA, PLCs, or DCS systems.
   • Redundancy: Optional dual-processor redundancy to ensure continuous operation during failures.
   • Environmental Resilience:
     • Operating temperature: -40°C to +85°C (industrial-grade).
     • Resistant to shock, vibration, and electromagnetic interference (EMI).
3. Advanced Capabilities
   • Adaptive Tuning: Auto-tuning algorithms for optimizing control loops under varying load conditions.
   • Diagnostics: Real-time fault detection, alarms, and event logging for predictive maintenance.
   • Safety Compliance: Meets SIL 2/3 (Safety Integrity Level) standards for safety-critical systems.

Applications

The Peak150 is deployed in diverse industries, including:

• Power Generation: Gas turbines, diesel generators, and combined heat and power (CHP) plants.
• Oil & Gas: Compression stations, pipeline pumping, and offshore platforms.
• Marine: Propulsion control and auxiliary engine management.
• Industrial Processes: Paper mills, chemical plants, and water treatment facilities.

Advantages

• Reliability: Robust design ensures uninterrupted operation in harsh environments.
• Scalability: Easily integrates with existing Woodward control systems (e.g., NetCon, ProAct) or third-party platforms.
• User-Friendly Interface: Configurable via Woodward ToolKit software, enabling quick setup and parameter adjustments.
• Global Support: Backed by Woodward’s worldwide technical service network.

Installation & Configuration

• Mounting: Designed for DIN rail or panel mounting in control cabinets.
• Configuration:
  • Programmable via Woodward ToolKit software with intuitive graphical interfaces.
  • Pre-configured templates for common applications (e.g., turbine control, generator synchronization).
• Firmware Updates: Regular updates enhance functionality and cybersecurity.

Support & Documentation

For technical details, refer to:

• Product Manuals: Available on Woodward’s official website (search for Peak150).
• Certifications: Compliant with CE, UL, ATEX, and IEC standards.
• Service: Contact Woodward’s engineering support for troubleshooting or retrofitting.

The Woodward Peak150 exemplifies Woodward’s expertise in delivering rugged, intelligent control solutions for demanding industrial environments. Its versatility and reliability make it a cornerstone of modern engine and turbine management systems.
