Introduction to Eaton XV-102-D8-70TWR-10
XV-102-D8-70TWR-10 Product Overview
The Eaton XV-102-D8-70TWR-10 is a compact and cost-effective industrial human-machine interface (HMI) panel belonging to Eaton’s XV100 series, specifically designed for intuitive monitoring and control of small to medium-sized automation systems. It serves as a reliable interaction bridge between operators and on-site equipment, enabling real-time visualization of key process data, simple parameter configuration, and basic system status monitoring. Equipped with a 7-inch color TFT resistive touch display, the panel ensures stable operation and precise input even in dusty industrial environments or when operated with gloves. Featuring multiple communication interfaces including Ethernet, RS-232, RS-485, and PROFIBUS, it supports seamless integration with Eaton’s entry-level PLCs and mainstream industrial control devices.
XV-102-D8-70TWR-10 Technical Specifications
-
Product Model: XV-102-D8-70TWR-10
-
Product Type: Compact Industrial HMI Panel (XV100 Series)
-
Core Functions: Real-time process data visualization, basic parameter configuration, system status monitoring, message indication & confirmation, data logging with retentive memory, optional PLC function
-
Display Specifications: 7-inch color TFT resistive touch display; 16:9 widescreen format for clear data presentation; Reliable 4-wire touch technology suitable for industrial operation
-
Processor & Memory: Industrial-grade processor ensuring stable operation; Support for removable SD card expansion for flexible data storage
-
Communication Interfaces: 1 x 10/100 Mbps Ethernet port; 1 x RS-232 port; 1 x RS-485 port; 1 x PROFIBUS interface; USB Host and USB Device ports; SD card slot for expansion
-
Software Compatibility: Compatible with X Soft-CODESYS and Galileo operating systems; Supports programming and visualization via CODESYS V2/V3 and Galileo software
-
Power Supply: 24 VDC input; Fanless passive cooling based on natural convection, low power consumption
-
Protection Class: Front side: IP65, NEMA 4X; Rear side: IP20; Suitable for front flush mounting in industrial control cabinets
-
Operating Environment: Operating temperature: 0°C to +50°C; Storage temperature: -20°C to +60°C; Complies with IEC/EN 61000-6-4, IEC/EN 61131-2, and EN 50178 standards
-
Mechanical Dimensions: Width: 135 mm, Height: 210 mm, Depth: 38 mm; Weight: 0.64 kg; Compact design supporting vertical installation for space-constrained applications
-
Installation Method: Front flush mounting; Inclination from vertical: ≤ ±45° (when using natural convection); Required clearance for heat dissipation
-
Certifications: CE, UL, cUL, DNV GL, EAC certified; RoHS compliant; UL File No.: E208621; Complies with CSA C22.2 No. 60950-1 and IEC/EN 60950 standards
