Introduction to Eaton XV-303-70-CE0-A00-1E
XV-303-70-CE0-A00-1E Product Overview
The Eaton XV-303-70-CE0-A00-1E is an advanced human-machine interface (HMI) panel belonging to Eaton’s XV300 series, specifically engineered for intuitive monitoring and control of industrial automation systems. It serves as a high-performance interactive hub between operators and control devices, enabling real-time visualization of process data, precise parameter configuration, and efficient system status management. Equipped with a 7-inch widescreen PCT multi-touch display, the panel supports intuitive gestures such as zooming and scrolling, delivering a user experience similar to modern smart devices while ensuring reliable operation in industrial environments. Featuring dual Ethernet interfaces and multiple serial communication ports, it supports seamless integration with mainstream industrial protocols and Eaton’s PLCs, enhancing the connectivity and scalability of automation architectures.
XV-303-70-CE0-A00-1E Technical Specifications
-
Product Model: XV-303-70-CE0-A00-1E
-
Product Type: Advanced Industrial HMI Panel (XV300 Series)
-
Core Functions: Real-time process data visualization, parameter configuration, gesture control operation, web visualization, multi-protocol communication, data logging
-
Display Specifications: 7-inch widescreen PCT multi-touch TFT display; Resolution: WSVGA (1024 x 600); Anti-reflective tempered glass for clear reading in various lighting conditions
-
Processor & Memory: 800 MHz industrial-grade processor (ARM Cortex A9) for smooth operation; Equipped with large-capacity memory for stable application running and data storage
-
Communication Interfaces: 2 x 10/100 Mbps Ethernet ports; 1 x RS-232 port; 1 x RS-485 port; 1 x CAN interface; 1 x USB port; Support for SD card expansion slot
-
Software Compatibility: Compatible with Eaton Visual Designer and CODESYS software; Supports web serving to Windows, Android & iOS devices; Pre-installed Windows Embedded Compact 7 Pro operating system
-
Power Supply: 24 VDC (19.2 VDC – 30 VDC wide voltage input); Fanless passive cooling design, low power consumption
-
Protection Class: Front panel: IP65; Rear side: IP20; Suitable for front flush mounting in industrial control cabinets
-
Operating Environment: Operating temperature: 0°C to +50°C; Storage temperature: -20°C to +60°C; Relative humidity: 10% – 90% (non-condensing); Complies with EN 61000-6-4 EMC standards
-
Mechanical Dimensions: Width: 6.7 in, Height: 4.4 in, Depth: 11.2 in; Weight: 2.15 lb; Compact design for easy integration
-
Installation Method: Front flush mounting; Convenient for on-site installation and maintenance
-
Certifications: CE marked; RoHS compliant; Meets global industrial application standards
