ABB 1SCA022697R2770 Miniature circuit breaker

$399.00

In stock

💥Name: Module/Controller/Touchpad/Driver/Load cell

Model: 1SCA022697R2770

🚚Delivery time: goods in stock

3️⃣6️⃣5️⃣Warranty: 12 months

Shipping fee: Shipping fee: Please contact customer service.

📦Product packaging: The seller provides complete packaging

🌐Customs clearance fee: not included

☎️Phone/WeChat:15359021002

📧Email: LuckyXiao.909@Gmail.com

📲WhatsApp+86 15359021002

 🆔Skype:+86 15359021002

❤️Other websites: www.szcxgk.com

(Note: The actual price is subject to the quotation.)

ABB 1SCA022697R2770 Overview

The ABB 1SCA022697R2770 is a compact, high-performance miniature circuit breaker (MCB) engineered to protect electrical circuits from overloads and short circuits in residential, commercial, and industrial installations. Part of ABB’s System Pro M compact® S200 series, this device combines reliable protection with ease of installation, making it ideal for safeguarding lighting, socket circuits, and control panels.


Key Technical Specifications

  1. Electrical Ratings
    • Rated Current (In)16 A (adjustable trip range may vary by model).
    • Rated VoltageAC 230/400 V (50/60 Hz).
    • Breaking Capacity6 kA (IEC 60898-1 standard).
    • Tripping CharacteristicsC-curve (medium starting current, suitable for general-purpose circuits).
  2. Mechanical & Design Features
    • Poles1P (single-pole) protection for phase and neutral.
    • Mounting: DIN rail compatible (EN 60715 standard) for quick installation.
    • Enclosure: Flame-retardant thermoplastic material with IP20 protection.
    • Contact Position Indicator: Visual indication of ON/OFF status.
  3. Protection & Safety
    • Overload Protection: Thermal tripping mechanism for prolonged overcurrents.
    • Short-Circuit Protection: Magnetic tripping for instantaneous fault interruption.
    • Isolation Function: Safe isolation during maintenance (compliant with IEC 60669-1).
  4. Environmental & Compliance
    • Operating Temperature-25°C to +55°C.
    • Standards: Complies with IEC 60898-1IEC 60947-2, and CE directives.

Core Functionalities

  1. Circuit Protection
    • Automatically disconnects power during overloads or short circuits to prevent equipment damage and fire hazards.
    • C-curve tripping balances protection for resistive and inductive loads (e.g., lighting, motors).
  2. User Safety
    • Ensures safe isolation of circuits during maintenance or repairs.
    • Arc-quenching design minimizes arc flash risks during fault interruption.
  3. Space-Saving Installation
    • Compact width (17.5 mm per pole) optimizes space in distribution boards.
    • Tool-free DIN rail mounting simplifies installation.
  4. Compatibility
    • Integrates seamlessly with ABB’s System Pro M compact® accessories (e.g., shunt releases, auxiliary contacts).
    • Compatible with standard DIN rail enclosures and panel designs.

Typical Applications

  • Residential: Protection of lighting circuits, sockets, and household appliances.
  • Commercial: Use in office buildings, retail spaces, and HVAC control panels.
  • Industrial: Integration into machinery, conveyor systems, and motor control centers (MCCs).
  • Renewable Energy: Circuit protection in solar PV distribution systems.

Advantages

  • Reliability: Precision-engineered tripping mechanisms ensure consistent performance.
  • Durability: Robust construction for long-term operation in diverse environments.
  • Flexibility: Modular design supports expansion with auxiliary modules (e.g., alarms).
  • Compliance: Meets global safety and performance standards for electrical installations.
