216NG63A Product Overview

216NG63A Technical Specifications

• Product Model: 216NG63A
• Product Type: Auxiliary DC Power Supply Unit (216 Series)
• Core Functions: Stable 24V DC power output, three-level surge protection (TVS tube, thermistor, gas discharge tube), short-circuit/overload/overvoltage protection, parallel capacity expansion, parallel redundancy (2 outputs), fault self-diagnosis, power status monitoring
• Power Specifications: Input voltage range: 36-312 V DC; Output voltage: 24 V DC; Output power: 150 W; Rated input current: 63 A (380V input); Power conversion efficiency: High-efficiency design for low energy consumption
• Protection Features: Three-level surge protection; Output short-circuit protection; Overload protection; Overvoltage protection; Effectively resists electromagnetic interference
• Operating Performance: Stable output voltage with low ripple; Fast response to load changes; Supports 2-unit parallel redundancy for uninterrupted power supply
• Environmental Ratings: Operating temperature: -20°C to +55°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20
• Mechanical & Installation: Rack-mounted (3 rack divisions required); Dimensions (approx.): 26.2 cm × 15.5 cm × 2.0 cm; Weight: approx. 1.2 kg; Supports wall-mounted or horizontal installation; Equipped with LED status indicators
• Compatibility: Fully compatible with ABB 216 series control systems; Matches ABB Procontrol series, AC800F/DCS controllers and peripheral devices
• Certifications & Compliance: Complies with industrial power supply safety standards; Passes strict reliability testing; Suitable for industrial automation and process control scenarios
• Application Adaptability: Provides power for DCS, PLC, robot control systems, power equipment monitoring devices and other industrial automation components
