Introduction to ABB 216VC62A HESG324442R13/C
HESG324442R13 Product Overview
The ABB 216VC62A HESG324442R13/C is a high-reliability voltage control module belonging to ABB’s 216 series, specifically designed for industrial distributed control systems (DCS). It serves as a core component for voltage signal monitoring, regulation, and protection in power-related industrial processes, enabling precise control of voltage parameters for equipment such as generators, transformers, and power distribution units. The module features galvanic isolation between channels and the system, effectively resisting electromagnetic interference in harsh industrial environments. Equipped with comprehensive self-diagnostic and fault alarm functions, it can promptly detect voltage anomalies, circuit faults, and other issues, ensuring the safe and stable operation of power systems. Its modular design facilitates easy installation and maintenance, while wide environmental adaptability makes it suitable for power generation, petrochemical, metallurgical and other key industrial fields, providing reliable voltage control support for industrial power systems.
HESG324442R13 Technical Specifications
-
Product Model: 216VC62A HESG324442R13/C
-
Product Type: Voltage Control Module (216 Series)
-
Core Functions: Voltage signal acquisition & regulation, overvoltage/undervoltage protection, fault self-diagnosis & alarm, signal conditioning & filtering, channel galvanic isolation, seamless DCS integration, voltage parameter monitoring & feedback
-
Power Supply: 24 V DC ±10% input; Built-in voltage stabilization and surge protection; Power consumption: ≤ 10 W (full load)
-
Voltage Specifications: Input voltage range: 0-100 V AC/DC; Output control signal: 4-20 mA DC / 0-10 V DC (selectable); Voltage measurement accuracy: ±0.2% FS
-
Communication Protocols: Supports PROFIBUS DP, Modbus RTU; Compatible with ABB DCS internal bus; High-speed data transmission for real-time voltage control
-
Isolation Performance: Channel-to-channel isolation: ≥ 2500 VAC; Channel-to-system isolation: ≥ 2500 VAC; Compliance with IEC 61000-4 anti-interference standards
-
Environmental Ratings: Operating temperature: -20°C to +55°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP30
-
Mechanical & Installation: DIN rail/panel-mounted; Modular design (approx. 140×100×50 mm); Weight: approx. 0.75 kg; Pluggable terminals for easy maintenance; LED status indicators (power, operation, fault)
-
Compatibility: Fully compatible with ABB 216 series control systems; Matches ABB AC800F/DCS controllers and I/O modules
-
Certifications & Protection: CE, UL certified; Complies with IEC 61131-2 industrial control standards; Equipped with overcurrent, short-circuit and overtemperature protection
Recommended ABB Same-Series & Related Models
-
ABB 216AB61 HESG324013R100: Protective relay module, for generator/transformer differential and overcurrent protection
-
ABB 216DB61 HESG324063R100: Industrial control module, integrating analog/digital signal acquisition and logic control
-
ABB 216DC61 HESG324064R100: Digital input module, specialized in high-speed acquisition of switch and sensor signals
-
ABB 216DA61 HESG324065R100: Analog input module, supporting 4-20 mA/0-10 V signal acquisition with high precision
-
ABB 216EA61b: Analog output module, providing 8-channel stable analog signals for industrial actuators
-
ABB 216EB61 HESG324066R100: Relay output module, offering 8-channel relay output for driving industrial equipment
-
ABB 216FC61: Frequency input module, for acquisition and processing of 0-10 kHz frequency signals
-
ABB 216AB62 HESG324014R100: Redundant protective relay module, for critical power equipment protection
-
ABB 216DD61: Digital I/O module, integrating 16 digital inputs and 16 digital outputs
-
ABB 216AE61: Temperature input module, supporting PT100/K-type thermocouple signal acquisition
-
ABB 216CA61: Communication interface module, enabling 216 series modules to connect with Ethernet networks
-
ABB 216ED61: Analog I/O combination module, with 4 analog inputs and 4 analog outputs
-
ABB 216FB61: Pulse output module, supporting 0-100 Hz pulse signal output for flow control
-
ABB 216AB63 HESG324015R100: Feeder protection relay module, integrating overcurrent and earth fault protection
-
ABB 216DC62: High-speed digital input module, with 32 channels for real-time signal acquisition
-
ABB 216VC61A: Voltage control module, with single-channel precise voltage regulation for small-scale systems
