ABB 3BHB017693R0001 communication interface module

ABB 3BHB017693R0001 Product Overview

The ABB 3BHB017693R0001 is a Communication Interface Module designed for integration into ABB’s AC 800M and Advant Controller 800 (AC 800) automation systems. It facilitates seamless communication between controllers, field devices, and higher-level systems, ensuring reliable data exchange in industrial automation environments. This module is critical for applications requiring robust connectivity in sectors such as power generation, oil and gas, and process manufacturing.

Key Technical Parameters

1. Communication Protocols
   • Supported Protocols:
     • PROFIBUS DP (Decentralized Peripherals).
     • Modbus RTU/TCP for legacy system integration.
     • OPC UA for modern industrial IoT (IIoT) connectivity.
   • Data Transfer Rate:
     • Up to 12 Mbps for PROFIBUS DP.
     • Ethernet ports support 10/100 Mbps (auto-negotiation).
2. Hardware Specifications
   • Interface Ports:
     • PROFIBUS DP connector (9-pin D-Sub).
     • Ethernet RJ45 port(s) for TCP/IP communication.
   • Redundancy: Supports redundant communication paths for fault tolerance.
   • Power Supply:
     • 24 V DC (typical industrial voltage).
     • Power consumption: ≤ 3 W (low-energy design).
3. Environmental & Mechanical
   • Operating Temperature: -25°C to +70°C (-13°F to +158°F).
   • Storage Temperature: -40°C to +85°C (-40°F to +185°F).
   • Protection Class: IP20 (for installation in control cabinets).
   • Humidity: 5–95% (non-condensing).
4. Certifications
   • Complies with CE, UL, and IEC 61131 standards.
   • Suitable for use in industrial and hazardous areas (ATEX/IECEx compliance dependent on configuration).

Core Functions

1. Multi-Protocol Communication
   • Acts as a gateway between the AC 800M controller and field devices via PROFIBUS DP, Modbus, or Ethernet.
   • Enables integration of third-party devices into ABB’s automation ecosystem.
2. Redundancy & Reliability
   • Supports redundant communication paths to ensure uninterrupted data flow during network failures.
   • Hot-swappable design for maintenance without system downtime.
3. Real-Time Data Exchange
   • Enables deterministic communication for time-critical applications (e.g., safety systems, process control).
   • Synchronizes data between distributed I/O modules and controllers.
4. Diagnostics & Troubleshooting
   • Built-in LED indicators for status monitoring (power, activity, errors).
   • Advanced diagnostics via ABB’s Control Builder M software for fault detection and resolution.
5. Scalability
   • Compatible with ABB’s S800 I/O series for expanding system I/O points.
   • Integrates with ABB’s 800xA Distributed Control System (DCS) for enterprise-wide automation.

Typical Applications

• Power Plants: Turbine control, grid synchronization, and substation automation.
• Oil & Gas: Pipeline monitoring, safety instrumented systems (SIS), and offshore platforms.
• Chemical Processing: Batch control, reactor monitoring, and safety interlocks.
• Manufacturing: Robotics coordination, conveyor systems, and quality assurance.

Software & Configuration

• Control Builder M: ABB’s engineering tool for configuring communication parameters, mapping I/O, and programming logic.
• OPC UA Server/Client: Enables secure data exchange with SCADA, MES, and cloud platforms.
• Field Information Manager (FIM): For asset management and predictive maintenance.

Advantages

• High Availability: Redundant communication paths and hot-swappable design minimize downtime.
• Interoperability: Bridges legacy and modern protocols for hybrid automation environments.
• Cybersecurity: Supports secure communication protocols (e.g., OPC UA with encryption).

The ABB 3BHB017693R0001 is a versatile and robust communication module that ensures reliable connectivity and system integration in demanding industrial applications.
