Introduction to ABB 5SHY35L4503 3BHB004693R0001

5SHY35L4503 3BHB004693R0001 Product Overview

5SHY35L4503 3BHB004693R0001 Technical Parameters

• Product Model: 5SHY35L4503 3BHB004693R0001
• Product Type: Integrated Gate-Commutated Thyristor (IGCT) Module (5SHY Series)
• Core Functions: High-power AC/DC conversion, fast switching control, voltage and current regulation, power transmission optimization, built-in coordination with overvoltage/overcurrent protection systems
• Electrical Parameters: Rated on-state current (IT(AV)): 3500 A; Peak repetitive off-state voltage (VDRM)/reverse voltage (VRRM): 4500 V; Non-repetitive peak surge current (ITSM): 8000 A (8.3 ms); Peak on-state voltage drop (VTM): ≤ 1.8 V (typical)
• Thermal & Cooling: Operating junction temperature range (TJ): -40°C to +125°C; Cooling method: Forced air cooling or water cooling; Integrated ceramic substrate and high-efficiency metal radiator
• Structural Features: Press-fit ceramic package; Standardized modular design for easy installation and replacement; Supports parallel/series connection for power rating expansion
• Protection Performance: Coordinates with external circuits for rapid fault shutdown; Strong anti-vibration and anti-impact capabilities; High insulation strength and electromagnetic interference (EMI) resistance
• Environmental Ratings: Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP20
• Mechanical & Installation: Dimensions (approx.): 250 mm × 180 mm × 60 mm; Weight: approx. 3.2 kg; Rack or panel mounting design; Standardized terminals for convenient wiring
• Compatibility: Fully compatible with ABB ACS 6000 high-voltage inverter systems; Seamless integration with ABB power electronic control units; Suitable for parallel/series operation with other 5SHY series modules
• Certifications & Compliance: CE certified; Complies with relevant high-power semiconductor device standards; RoHS compliant, using environmentally friendly materials
• Application Adaptability: Suitable for HVDC transmission, FACTS devices, industrial frequency converters, motor drives (rolling mills, mine hoists), and wind/solar inverter systems; Ideal for large-scale power transmission and industrial drive scenarios
