Introduction to ABB 5SHY4045L0004 3BHB021400R0002
The ABB 5SHY4045L0004 (order number: 3BHB021400R0002) is a high-power thyristor module, serving as the “energy core” in medium-voltage industrial drive systems. As a key component of ABB’s ACS 6000 series medium-voltage frequency converters, it undertakes the critical task of precise current switching and voltage regulation in power conversion processes. This module integrates the high voltage-withstanding capability of thyristors and efficient switching performance, specializing in handling large currents and high voltages to drive heavy-duty equipment such as mining hoists, steel rolling mills, and large fans. It is widely applied in industries including metallurgy, mining, and petrochemicals, where its press-pack structure ensures minimal contact resistance and efficient heat dissipation. Equipped with built-in overcurrent, overvoltage, and overheating protection mechanisms, it guarantees stable operation in harsh industrial environments, directly determining the reliability and efficiency of the entire drive system.
3BHB021400R0002 Key Technical Specifications
-
Device Type: High-power thyristor (SCR) module for medium-voltage drives
-
Rated Voltage: 4000 V (V DRM/V RRM, reverse repetitive peak voltage)
-
Rated Current: 4500 A (I T(RMS), root mean square on-state current)
-
Surge Current Capacity: ≥60 kA (I TSM, 1-cycle surge current withstand)
-
Gate Trigger Parameters: Trigger current 200-500 mA (I GT); trigger voltage 1.5-3.0 V (V GT)
-
Switching Performance: Turn-off time ≤100 μs (t q); low conduction loss
-
Thermal Characteristics: Junction-to-baseplate thermal resistance 0.003°C/W; operating junction temperature -40°C to +125°C
-
Insulation Performance: 5000 V AC insulation voltage (1-minute withstand)
-
Cooling Method: Double-sided forced air cooling for efficient heat dissipation
-
Mechanical Design: Press-pack/bolt-down mounting; compatible with dedicated heat sinks
-
Protection Features: Built-in dv/dt and di/dt monitoring; overcurrent/overvoltage/overtemperature protection
-
Certifications: CE, UL, IEC 60747-6 compliant; RoHS certified
Recommended ABB Related Models
-
ABB 5SHY3545L0014: Asymmetric IGCT module (4500 V/4000 A), ideal for ACS 5000 series converters in steel rolling mills
-
ABB 5SHY65L4510: High-voltage IGCT module (4500 V), designed for HVDC and renewable energy inverter systems
-
ABB 5SHY4035L0002: Lower current variant (3500 A/4000 V), cost-effective for medium-power fans and pumps
-
ABB 5SHY4050L0006: High-current thyristor module (5000 A/4000 V), suitable for mining hoist drives
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, coordinates with 5SHY4045L0004 in integrated drive control systems
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, transmits control signals to 5SHY4045L0004’s drive unit
-
ABB TP854 3BSE025349R1: 7-inch HMI, monitors 5SHY4045L0004’s temperature and current status on-site
-
ABB XVC 722 AE101 3BHB002751R0101: Process control module, regulates 5SHY4045L0004’s switching frequency in petrochemical compressors
-
ABB AI810 3BSE032456R1: 8-channel analog input module, collects 5SHY4045L0004’s operational data (current/voltage)
-
ABB DO810 3BSE032452R1: 16-channel digital output module, triggers protection actions for 5SHY4045L0004 in fault scenarios
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time control of 5SHY4045L0004 in metallurgy drives
-
ABB PCD237A101 3BHE028915R0101: Distributed I/O module, expands monitoring points for 5SHY4045L0004-based systems
-
ABB ACS 6000: Medium-voltage frequency converter, original application platform for 5SHY4045L0004
-
ABB TB852 3BSC950263R1: Redundant analog output module, feeds precise control signals to 5SHY4045L0004’s gate driver View more …..
