Introduction to ABB AO810V2 3BSE038415R1

AO810V2 3BSE038415R1 Product Overview

AO810V2 3BSE038415R1 Technical Parameters

• Product Model: AO810V2 3BSE038415R1
• Product Type: Analog Output Module (AO Series, Upgraded Version)
• Core Functions: Digital-to-analog signal conversion, high-precision analog output, signal isolation & amplification, channel status monitoring, fault diagnosis & alarm, self-calibration
• Power Supply: 24V DC input (19.2V-28.8V DC range); ≤5W power consumption; Overcurrent, overvoltage & reverse polarity protection
• Output Specifications: 8 analog output channels; Configurable output signals: 4-20mA current / 0-10V voltage; Output accuracy: ±0.1% of full scale; Resolution: 16-bit; Response time: ≤5ms; Load capacity: Up to 600Ω for current output, ≥10kΩ for voltage output
• Communication Protocols: PROFIBUS DP, Modbus RTU; Supports real-time data exchange with upper-level controllers and DCS
• Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Vibration resistance: 2G (10-150Hz); Shock resistance: 15G
• Mechanical & Installation: DIN rail-mounted; Dimensions (approx.): 120mm × 100mm × 45mm; Net weight: approx. 0.48kg; Plug-in terminals for easy wiring and maintenance; LED indicators for power, channel status & fault
• Protection Features: Output overcurrent & short-circuit protection; Channel-to-power supply isolation; Anti-EMI design; Built-in fault self-diagnosis and alarm indication
• Compatibility: ABB System 800xA DCS, AC800M controllers, other AO series modules, standard industrial actuators and regulators
• Certifications: CE certified; Complies with IEC 61131-2 industrial control standards; Passes strict EMC testing
• Applications: Petrochemical plants, metallurgical facilities, thermal power plants, water treatment systems, manufacturing production lines; Precision process control, industrial automation and distributed control systems

Recommended ABB Same-Series Models

1. ABB AO810 3BSE008522R1: Standard analog output module, 8 channels for general process control scenarios
2. ABB AO820V2 3BSE038416R1: Upgraded 16-channel analog output module for large-scale control systems
3. ABB AO830 3BSE008524R1: High-precision analog output module, ±0.05% full-scale accuracy for ultra-precise regulation
4. ABB AO815 3BSE008525R1: 4-channel compact analog output module for space-constrained installations
5. ABB AO840 3BSE008526R1: High-speed analog output module, ≤3ms response time for fast-response control systems
6. ABB AO850 3BSE008527R1: Redundant analog output module, dual-channel design for safety-critical applications
7. ABB AO860 3BSE008528R1: Isolated analog output module for high-interference industrial environments
8. ABB AO811 3BSE008529R1: Single-channel analog output module for independent precision regulation tasks
9. ABB AO821 3BSE008530R1: Mixed-signal output module, 8 analog outputs + 8 digital outputs for complex control scenarios
10. ABB AO831 3BSE008531R1: High-voltage analog output module, 0-20V output range for special industrial actuators
11. ABB AO841 3BSE008532R1: Low-power analog output module, energy-saving design for low-consumption automation systems
12. ABB AO851 3BSE008533R1: Ethernet-enabled analog output module, supports Ethernet/IP protocol for distributed control systems
13. ABB AO861 3BSE008534R1: Signal conditioning analog output module, integrated signal amplification for long-distance transmission
14. ABB AO812 3BSE008535R1: 2-wire analog output module, compatible with 4-20mA loop-powered actuators
15. ABB AO832 3BSE008537R1: Intelligent analog output module with self-calibration and status monitoring functions
