Introduction to ABB B5EEd HENF105082R4
HENF105082R4 Product Overview
The ABB B5EEd HENF105082R4 is a high-reliability industrial control signal module belonging to ABB’s B5EEd product series, specifically designed for signal conditioning and conversion in industrial automation systems. It serves as a crucial link between field sensors/transmitters and upper-level control systems (such as PLC and DCS), responsible for converting weak analog signals (like temperature, pressure, and flow) into standard industrial signals that can be accurately recognized and processed by controllers. Equipped with advanced signal isolation and anti-interference technology, the module effectively suppresses electromagnetic interference and voltage fluctuations in harsh industrial environments, ensuring stable and accurate signal transmission. Featuring a compact modular design, it supports flexible system expansion and easy DIN rail installation, which helps simplify cabinet layout and reduce maintenance workload.
HENF105082R4 Technical Specifications
-
Product Model: B5EEd HENF105082R4
-
Product Type: Industrial Control Signal Module
-
Core Functions: Analog signal conditioning, signal conversion, signal isolation, anti-interference processing, stable signal transmission
-
Input Signal: Supports weak analog signals (e.g., 0-10mV, 4-20mA); Compatible with various sensors (temperature, pressure, flow sensors)
-
Output Signal: Standard industrial signals (4-20mA, 0-10V); High signal conversion accuracy
-
Communication Capability: Supports industrial communication protocols; Seamless integration with ABB PLC/DCS systems
-
Power Supply: 24V DC ±10%; Power consumption ≤8W
-
Isolation Performance: Input-output isolation voltage ≥1000V AC; Channel-channel isolation voltage ≥500V AC
-
Operating Environment: Temperature range: -25°C to +65°C; Humidity: 5-95% (non-condensing); Anti-electromagnetic interference compliant with IEC 61000-6-2/4
-
Mechanical Dimensions: 35mm × 100mm × 120mm; Weight: Approximately 0.18kg
-
Safety Features: Overvoltage protection, short-circuit protection, reverse polarity protection
-
Installation Method: 35mm DIN rail mounting; Tool-free wiring terminals
-
Certifications: CE, UL, IEC 61131-2 compliant; Suitable for global industrial applications
