Introduction to ABB BDD110 HNLP205879R1
BDD110 Product Overview
The ABB BDD110 (order code: HNLP205879R1) is a high-performance multi-functional industrial controller module, engineered to deliver precise control and reliable signal processing for complex automation systems. Integrating analog and digital I/O capabilities with advanced microprocessor technology, it serves as a core control unit in diverse fields—from manufacturing production lines and wind/solar energy management systems to chemical process control and building automation. A key strength lies in its broad protocol compatibility, supporting Modbus, Profibus, and other industrial communication standards to seamlessly connect with PLCs, DCS, sensors, and actuators. Equipped with 4 dedicated analog input channels and configurable digital I/O, it efficiently converts field signals and executes custom control logic. Designed for harsh industrial environments, it features comprehensive protection against overload, short circuits, and overheating, while its compact structure (200mm×100mm×50mm) and dual installation options (DIN rail or panel mount) ensure flexibility in space-constrained control cabinets.
BDD110 Technical Specifications
-
Product Model: BDD110 (Order Code: HNLP205879R1)
-
Product Type: Multi-functional Industrial Controller Module
-
Series Affiliation: ABB Industrial Automation Controller Series
-
Core Functions: Analog/digital signal processing, custom control logic execution, multi-protocol communication, fault detection and alarm
-
I/O Configuration: 4×analog input channels; Configurable digital I/O (varies by application); Supports 4-20mA current/0-10V voltage signals
-
Electrical Ratings: Input voltage 220V AC; Output power 1.5kW; Output current 7.5A; Rated voltage 440V AC
-
Communication Capability: Supports Modbus, Profibus; RS-232/RS-485 serial interfaces; 10/100 Base-TX Ethernet option
-
Processing Performance: Advanced microprocessor; Output frequency up to 50kHz; Control response time ≤10ms
-
Protection Features: Overload protection, short-circuit protection, overheating protection, voltage fluctuation tolerance
-
Power Supply: 220V AC ±10%; Typical power consumption dependent on load (max 1.5kW)
-
Operating Environment: Temperature -20°C to +60°C; Humidity 5-95% (non-condensing); Protection rating IP20 (control room)/IP65 (enhanced variant)
-
Mechanical Features: DIN rail/panel mount; Dimensions 200mm×100mm×50mm (L×W×H); Weight ~1.2kg
-
Additional Functions: Real-time clock, critical data storage, channel-level self-diagnosis, LED status indicators
-
Compatibility: ABB AC 800M DCS, S100 I/O systems, third-party PLCs via standard protocols
-
Certifications: CE, UL certified; Complies with IEC 61131-2 industrial control standards
