Introduction to ABB CP405 A0 1SAP500405R0001

1SAP500405R0001 Product Overview

1SAP500405R0001 Technical Specifications

• Product Model: CP405 A0 1SAP500405R0001
• Product Type: Industrial Operator Panel (HMI)
• Core Functions: Real-time system status monitoring, parameter configuration and modification, operational command input, fault alarm display, historical data query, intuitive human-machine interaction
• Display Specifications: 5.7-inch high-contrast LCD display; Resolution: 320 × 240 pixels; Backlight type: LED; Backlight lifespan: ≥ 50,000 hours
• Power Supply: 24 V DC input; Input voltage range: 19.2 V DC to 28.8 V DC; Power consumption: ≤ 10 W; Built-in overcurrent and overvoltage protection
• Communication Interfaces: 1 × Ethernet port (supports TCP/IP, Modbus TCP); 1 × RS-485 serial port (supports Modbus RTU); 1 × USB port (for program download and data transfer)
• Operation Features: Membrane keypad with tactile feedback; Customizable function keys; Support for multi-language display; Simple and intuitive operation interface
• Environmental Ratings: Operating temperature: 0°C to +50°C; Storage temperature: -20°C to +60°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP65 (front panel); Vibration resistance: 10-150 Hz, 0.15 mm amplitude
• Mechanical & Installation: Panel-mounted design; Dimensions (approx.): 190 mm × 140 mm × 55 mm; Weight: approx. 0.8 kg; Easy-to-install snap-on structure; Standard mounting cutout for convenient integration
• Compatibility: Fully compatible with ABB AC800M series controllers; Seamless integration with ABB System 800xA; Supports connection with standard industrial PLCs and automation devices
• Certifications & Compliance: CE certified; Complies with IEC 61131-2 industrial control standards; Passes strict EMC (Electromagnetic Compatibility) testing
• Application Adaptability: Suitable for manufacturing, process control, power generation, and water treatment industries; Ideal for production line monitoring, equipment operation control, and process parameter adjustment scenarios
