Introduction to ABB CS513 3BSE000435R1
The ABB CS513 (order number: 3BSE000435R1) is a high-performance multi-functional communication and control module, celebrated as the “network integration hub” in industrial automation systems. As a key product of ABB’s Advant OCS series, it integrates data processing, multi-protocol conversion, and distributed control capabilities, specializing in enabling seamless data exchange between PLCs, DCS, and field devices across diverse industries . Its robust design supports multiple communication protocols including Ethernet/IP, Modbus RTU/TCP, PROFIBUS, and MasterBus 300E, making it widely applied in power generation (substation monitoring), petrochemicals (reactor process control), and factory automation (production line coordination) . Equipped with a 32-bit RISC processor and industrial-grade EMC protection (compliant with IEC 61131-2 standards), the module ensures stable operation in harsh environments with strong electromagnetic interference . The compact DIN rail-mounted structure optimizes cabinet space, while built-in self-diagnostic functions and status reporting simplify on-site troubleshooting, significantly enhancing the reliability and connectivity of industrial control networks.
3BSE000435R1 Key Technical Specifications
-
Device Type: Multi-protocol communication & control module (Advant OCS series)
-
Core Processor: 32-bit RISC processor; 100 MHz clock speed
-
Communication Protocols: Ethernet/IP, Modbus RTU/TCP, PROFIBUS, MasterBus 300E, RS-232/485
-
Data Transmission: Up to 500 kbps (MasterBus 300E); 115.2 kbps (RS-485); supports 32 nodes max for RS-485
-
I/O Capacity: Supports up to 256 digital I/O points; expandable with auxiliary modules
-
Power Supply: 24V DC (nominal); input range 18-36V DC; total power dissipation ≤ 8W
-
Memory Configuration: 128 KB RAM; 512 KB Flash memory
-
Operating Environment: Temperature -20°C to +70°C; humidity 5-95% (non-condensing); storage temp -40°C to +85°C
-
Physical Specifications: 120mm × 80mm × 35mm; weight ~0.2kg; 35mm DIN rail mounting
-
Protection Features: IP20 protection level; overvoltage/overcurrent protection; EMC compliant with industrial standards
-
Interfaces: DB-9 male connectors; Ethernet port (IEEE 802.3 compliant); RS-232/485 terminals
-
Certifications: CE, UL, ATEX Zone 2, TUV compliant; RoHS certified
Recommended ABB Related Models
-
ABB CS513K01 3BSE004772R1: Enhanced control variant with 8 analog inputs/16 digital I/O, ideal for hybrid signal systems in food processing
-
ABB CS513AK01 3BSE091971R1: High-speed communication module, complements CS513 for 1 Mbps data transmission in automotive assembly lines
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, core unit processing data from CS513 in integrated DCS
-
ABB CI858K01 3BSE018135R1: Multi-protocol communication module, expands CS513’s connectivity to remote SCADA systems
-
ABB ACS 580: Low-voltage frequency converter, receives control signals from CS513 for motor speed regulation
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes CS513’s communication status and fault alarm information on-site
-
ABB AI810 3BSE032456R1: 8-channel analog input module, transmits sensor data to CS513 for centralized processing
-
ABB DO810 3BSE032452R1: 16-channel digital output module, executes control actions based on CS513’s command signals
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time data interaction with CS513
-
ABB AC500 PLC: Compact controller, pairs with CS513 for small-scale automation in water treatment plants
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, connects CS513 to ABB 800xA platform
-
ABB REF620: Digital relay protector, collaborates with CS513 to safeguard power system equipment
-
ABB UNITROL 1020: Excitation regulator, integrates with CS513 for medium-sized generator control
-
ABB PCD235B101 3BHE032025R0101: 16-channel analog input module, expands CS513’s signal acquisition range in petrochemicals
