Introduction to ABB E3EB HENF315129R1

HENF315129R1 Product Overview

HENF315129R1 Technical Specifications

• Product Model: E3EB HENF315129R1
• Product Type: Industrial Control Module (Redundant Channel Module)
• Core Functions: Dual-channel redundant design, industrial process control & monitoring, multi-protocol data transmission, programmable configuration, overload/short-circuit/overtemperature protection, fault self-diagnosis & alarm, signal acquisition & conversion, network data conversion
• Power Supply: Optional 24 V DC ±20% or 220 V AC input; Built-in voltage stabilization and surge protection; Maximum rated current: 0.5 A; Output frequency: 50 kHz
• Input/Output Specifications: Supports 0-10 V DC output signal; Compatible with multiple types of industrial sensors and actuators; Channel isolation protection for stable signal transmission
• Communication Protocols: Supports Modbus RTU, Ethernet (TCP/IP, UDP); Facilitates seamless data exchange with upper-level control systems and field devices
• Response Performance: Equipped with high-performance processor for high-speed data processing; Fast fault switching between redundant channels to ensure continuous operation
• Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +85°C; Relative humidity: 5%-95% (non-condensing); Strong anti-interference capability for harsh industrial environments
• Mechanical & Installation: Compact design (approx. 100×50×20 mm); Weight: approx. 50 g; Easy to install and maintain; DIN rail/panel-mounted; LED status indicators for real-time channel monitoring
• Compatibility: Fully compatible with ABB DCS/PLC systems; Seamless integration with ABB E3 series modules and industrial automation equipment
• Certifications & Protection: Certified product; Overload, short-circuit, and overtemperature protection; Complies with relevant industrial automation safety standards

Recommended ABB Same-Series Models

1. ABB E3ED: Industrial process control module with built-in PLC functions, suitable for precise parameter regulation and equipment monitoring
2. ABB E3EP HENF315276R1: Programmable logic controller (PLC) with expandable I/O, for industrial process control scenarios
3. ABB E3EC HENF315125R1: Industrial control module with IP67 protection, supporting multi-protocol communication for harsh environment applications
4. ABB E3EFa HENF452750R1: High-performance controller module, supporting multiple control modes and remote monitoring for industrial process control
5. ABB O3EB HENF315128R1: Redundant channel control module, with dual-channel backup for critical system control
6. ABB O3ES HENF445789R1: Industrial automation control module, supporting EtherCAT and PROFINET for robotic control systems
