Introduction to ABB G3ESa HENF318736R1
HENF318736R1 Product Overview
The ABB G3ESa HENF318736R1 is a high-performance electronic fieldbus valve system module, belonging to ABB’s G3 series. Specifically designed for industrial automation and pneumatic valve control scenarios, it integrates fieldbus communication, I/O signal processing, and visual diagnostic functions, serving as a core component for seamless connection between programmable logic controllers (PLC) and pneumatic valves, sensors, and other field devices. The module features an innovative graphic display for easy configuration, commissioning, and real-time status monitoring, significantly reducing maintenance time. With a modular clip design, it allows quick module removal and replacement without dismantling the manifold, enhancing operational efficiency. Boasting IP65 protection class and strong anti-interference performance, it operates stably in harsh industrial environments such as manufacturing, automotive assembly, and packaging industries, widely used in automated production lines to realize efficient valve control and data transmission.
HENF318736R1 Technical Specifications
-
Product Model: G3ESa HENF318736R1
-
Product Type: Electronic Fieldbus Valve System Module (G3 Series)
-
Core Functions: Pneumatic valve control, I/O data transmission, graphic display for configuration & diagnostics, fault self-diagnosis (open/short load, low power, missing module), plug-and-play integration, distributed I/O connection, network error logging
-
Power Supply: 24 V DC input; Voltage tolerance: -10% / +10%; Electronic device current consumption: 0.03 A; Total valve current: 4 A
-
Input/Output Specifications: Supports analog/digital inputs (NPN/PNP); Compatible with 4-20 mA, 0-10 V signals; Maximum expandable I/O modules: 15; Up to 32 valve solenoids per manifold
-
Communication Protocols: Supports DeviceNet™, Ethernet/IP™, PROFIBUS DP, PROFINET, Powerlink, Modbus/TCP, DeviceLogix
-
Response Performance: Fast data transmission; Plug-and-play capability without special configuration; Short troubleshooting cycle via visual diagnostics
-
Environmental Ratings: Operating temperature: -10°C to +50°C; Storage temperature: -20°C to +60°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP65
-
Mechanical & Installation: Compact design (approx. 87×113×30 mm); Weight: approx. 0.235 kg; DIN rail-mounted; Clip design for easy assembly/disassembly; 7/8″ 4-pin multi-core plug connection
-
Compatibility: Fully compatible with ABB G3 series modules; Interfaces to valves with flow rates of 400-600 l/min ANR; Supports centralized/distributed application scenarios
-
Certifications & Protection: ATEX certified; Overcurrent, short-circuit protection; Complies with industrial automation safety and communication standards
Recommended ABB Same-Series Models
-
ABB G3FCb HENF458568R1: Terminal board controller module, for signal transmission and actuator control in G3 series systems
-
ABB G3FK HENF452878R1: Embedded control card with analog I/O conversion, suitable for G3 series sensor data processing
-
ABB G3ENa HENF450268R2: Intelligent electronic module, supporting multi-protocol communication for G3 fieldbus systems
-
ABB G3 Subbus 240-241: G3 series subbus module, expanding I/O capability for distributed valve control systems
-
ABB O3ES HENF445789R1: Industrial automation control module, supporting EtherCAT and PROFINET for robotic control
-
ABB O3EGb HENF315118R2: Multi-protocol control module, enabling seamless integration with G3 series systems
-
ABB E3EP HENF315276R1: Programmable logic controller (PLC) with expandable I/O, matching G3 series valve control
-
ABB O3EHa HENF315087R2: Analog input control module with HART support, for high-precision signal acquisition in G3 systems
-
ABB G3ESa HENF318737R1: Enhanced G3 series module, with extended I/O channels for large-scale valve control
-
ABB O3EC HENF442581R1: Configurable I/O control module, adapting to G3 series multi-type signal processing
-
ABB AC500-eCo V3: Compact PLC module, compatible with G3 series fieldbus systems for smart factories
-
ABB INPM01: Process monitoring module, enabling real-time data analysis for G3-based automation systems
-
ABB INPD01: High-precision data acquisition module, matching G3 series sensor signal processing needs
-
ABB G3 Series Communication Module: Specialized fieldbus communication module, supporting multiple protocols for G3 system networking
-
ABB G3 Series Input Module: Analog/digital input module, expanding signal acquisition capability for G3 valve systems
