Introduction to ABB G3FE HENF452697R1
G3FE HENF452697R1 Product Overview
The ABB G3FE HENF452697R1 is a high-performance industrial control card module, tailored for real-time process control and motion management in discrete manufacturing, petrochemical, and power automation scenarios. As a programmable core component, it integrates advanced control algorithms and high-speed data processing capabilities, supporting precise regulation of temperature, pressure, and flow parameters, as well as motion control for automated production lines and robotic systems. A standout feature is its multi-protocol compatibility, including Modbus, Profibus, CAN, and Ethernet/IP, enabling seamless data exchange with DCS, PLCs, and field intelligent devices. Equipped with 16 digital input channels and 16 relay output channels, it balances signal acquisition and control execution, while its 550μs processing speed ensures minimal latency for time-critical tasks. Designed with rugged aluminum housing and IP20 protection, it operates stably in harsh industrial environments (-20°C to +85°C), and supports remote diagnosis and maintenance—reducing on-site service costs and improving system availability.
G3FE HENF452697R1 Technical Specifications
-
Product Model: G3FE HENF452697R1
-
Product Type: Industrial Control Card Module
-
Series Affiliation: ABB G3FE Industrial Control Series
-
Core Functions: Real-time process control, motion control, multi-protocol data transmission, custom logic execution
-
I/O Configuration: 16×digital inputs (single-ended/differential); 16×relay outputs; Supports 4-20mA analog signal interaction
-
Processing Performance: Processing speed 550μs; Output frequency 100Hz; Program capacity 300 steps; Data capacity 200 data points
-
Communication Capability: Supports Modbus, Profibus, CAN, Ethernet/IP; RJ45 & RS-485 interfaces; Data transmission rate up to 100Mbps
-
Programmability: Supports text & graphical programming; Custom control logic and algorithm implementation
-
Power Supply: 24V DC ±20%; Max input current 0.5A; Power consumption ≤10W
-
Protection Features: Overload protection, short-circuit protection, electrostatic discharge (ESD) protection (±8kV)
-
Operating Environment: Temperature -20°C to +85°C; Humidity 5-95% (non-condensing); Protection rating IP20
-
Mechanical Features: DIN rail mount; Aluminum housing; Dimensions 140mm×80mm×35mm (L×W×H); Weight ~0.4kg
-
Output Specifications: Relay output rating 5A/250V AC; Analog output optional 0-10V DC
-
Compatibility: ABB AC 800M controllers, S800 I/O modules, ACS series frequency converters, third-party PLCs
-
Certifications: CE, UL certified; Complies with IEC 61131-2 industrial control standards
Recommended ABB Products
-
ABB PM864AK02 3BSE018161R1: AC 800M CPU module that synchronizes control logic with G3FE HENF452697R1 for large-scale DCS applications.
-
ABB AI835 3BSE008520R1: High-precision analog input module that provides sensor data to G3FE HENF452697R1 for precise regulation.
-
ABB CI854A 3BSE022363R1: Profibus DP module that expands G3FE HENF452697R1’s connectivity to fieldbus networks.
-
ABB ACS880: Frequency converter that receives speed control signals from G3FE HENF452697R1 for motor operation.
-
ABB Panel 800: HMI panel that displays real-time operating data and alarms from G3FE HENF452697R1.
-
ABB PU515A 3BSE032401R1: Redundant power supply that ensures stable 24V DC input for G3FE HENF452697R1.
-
ABB REF615 1MRK504153-BEN: Protection relay that sends fault signals to G3FE HENF452697R1 to trigger emergency control.
-
ABB DI830 3BSE008519R1: Digital input module that supplements G3FE HENF452697R1’s signal acquisition capability.
-
ABB BDD110 HNLP205879R1: Industrial controller module that collaborates with G3FE HENF452697R1 in complex control systems.
-
ABB 1TGE120010R1300: HMI operating unit that allows on-site configuration of G3FE HENF452697R1’s control parameters.
