Introduction to ABB LDMUI-001 61320946C
LDMUI-001 Product Overview
The ABB LDMUI-001 61320946C is an integrated industrial liquid crystal display and control module, belonging to ABB’s automation module series. It is specifically designed for industrial automation scenarios, integrating high-definition graphical display, real-time data visualization, signal acquisition and control, and multi-protocol communication functions. As a key human-machine interface (HMI) component, it enables operators to intuitively monitor industrial process parameters, view equipment status, and perform simple control operations. The module features a rugged design with IP65 protection class, effectively resisting dust, moisture, and electromagnetic interference in harsh industrial environments. With high precision and stability, it supports seamless integration with ABB PLC, DCS, and robot control systems, widely applied in manufacturing, power generation, chemical, and building automation fields. Its low-power design and compact structure ensure reliable long-term operation and flexible installation, providing efficient human-machine interaction support for industrial automation systems.
LDMUI-001 Technical Specifications
-
Product Model: LDMUI-001 61320946C
-
Product Type: Industrial LCD Display & Control Integrated Module (Automation Series)
-
Core Functions: High-definition graphical display, real-time data visualization, signal acquisition & control, analog/digital signal conversion, multi-protocol communication integration, human-machine interaction, equipment status monitoring
-
Display Specifications: Resolution: 1920×1080; Screen size: Optional 15.6-inch or 21.5-inch; Brightness: 300 cd/m²; Contrast ratio: 1000:1; Response time: 5 ms; Dot pitch: 0.179 mm×0.179 mm
-
Power Supply: 12 V DC input; Maximum input current: 5 mA; Low-power design for energy saving
-
Communication Protocols: Supports multiple industrial communication protocols; Compatible with ABB PLC, DCS, and robot control systems for seamless integration
-
Accuracy & Stability: Output accuracy up to ±0.05%; High stability with high-quality materials and advanced manufacturing processes
-
Environmental Ratings: Operating temperature: -10°C to +60°C; Storage temperature: -20°C to +70°C; Relative humidity: 5%-95% (non-condensing); Protection class: IP65
-
Mechanical & Installation: Compact structure; Dimensions (approx.): Customized based on screen size; Panel-mounted installation; Rugged housing resistant to industrial harsh conditions
-
Compatibility: Fully compatible with ABB automation systems; Matches ABB AC 800M, AC 700F controllers and S800/S500 I/O series
-
Certifications & Compliance: Complies with industrial automation safety standards; Certified with CO, CQ; Passes strict quality control and testing
-
Application Adaptability: Suitable for industrial control, automated production lines, power industry, robot control, building automation, and energy management systems
Recommended ABB Same-Series & Related Models
-
ABB Panel 800: Industrial touchscreen HMI, providing intuitive operation interface for process automation systems
-
ABB AC 800M PM851: Modular controller, supporting basic logic operations and small-scale I/O expansion for industrial control
-
ABB S800 I/O AI835: High-precision analog input module, with 16-bit resolution for sensitive signal acquisition
-
ABB S800 I/O AO835: Analog output module, supporting multi-range signal output for industrial actuators
-
ABB ControlMaster CM10: Panel-mounted single-loop controller, specialized in simple process regulation scenarios
-
ABB ScreenMaster SM500F: Paperless recorder, supporting real-time data recording and trend analysis for industrial processes
-
ABB AC 700F PM573: Mid-range controller, adapting to medium-scale process automation with multiple communication protocols
-
ABB S500 I/O DI830: Digital input module, expanding digital signal collection capability for automation systems
-
ABB S500 I/O DO830: Digital output module, driving industrial actuators for on-site equipment control
-
ABB Compact HMI 800: PC-based SCADA system, enabling centralized monitoring and management of industrial processes
-
ABB AC 800M PM861: High-performance controller, supporting complex control algorithms and large-scale I/O expansion
-
ABB S800 I/O CI854A: PROFIBUS communication module, realizing data exchange between controller and field devices
-
ABB Commander C1900-R: Circular chart recorder, suitable for continuous data recording in industrial production
-
ABB AC500 PM554: Cost-effective PLC, compatible with small-scale industrial automation and distributed control
-
ABB ControlMaster CM50: Advanced single-loop controller, supporting high-precision process control and multi-function expansion
-
ABB S900 I/O AI930: Isolated analog input module, with strong anti-interference capability for harsh industrial environments
