Introduction to ABB MPRC086444-005
MPRC086444-005 Product Overview
The ABB MPRC086444-005 is a high-performance process control module designed for ABB’s distributed control systems (DCS), specializing in precision regulation of industrial processes such as pressure, flow, temperature, and liquid level. It integrates advanced PID (Proportional-Integral-Derivative) control algorithms and multi-channel signal processing capabilities, enabling real-time analysis of sensor feedback and accurate output of control signals to actuators like valves and pumps. Widely applied in water treatment plants, chemical reactors, and HVAC systems, it maintains process stability by minimizing parameter fluctuations—especially critical in scenarios like constant-pressure water supply where steady output is essential. Equipped with anti-interference technology and self-diagnostic functions, it ensures reliable operation in noisy industrial environments and provides timely alerts for faults such as signal loss or overload. Fully compatible with ABB’s AC 800M and System 800xA platforms, it supports seamless data exchange via industrial Ethernet, facilitating centralized monitoring and remote parameter tuning.
MPRC086444-005 Technical Specifications
-
Product Model: MPRC086444-005
-
Product Type: High-performance process control module
-
Series Affiliation: ABB MPRC Industrial Process Control Series
-
Core Functions: Advanced PID control, multi-channel signal processing, process parameter regulation, fault self-diagnosis
-
I/O Configuration: 4 analog input channels (4-20mA/0-10V), 2 analog output channels (4-20mA), 4 digital input/output channels (configurable)
-
Control Precision: PID regulation accuracy ±0.1% of full scale; Signal sampling rate 100 samples/second
-
Input Signal Compatibility: Supports thermocouple (K/J type), RTD (PT100), and standard industrial sensors
-
Communication Interface: 2×Ethernet ports (supports PROFINET/Modbus TCP); 1×RS485 backup port
-
Protection Features: Signal isolation (2500Vrms), overload protection, reverse polarity protection, signal loss alarm
-
Power Supply: 24VDC (18-30VDC range); Redundant input supported; Power consumption ≤8W
-
Operating Environment: Temperature -20°C to +65°C; Humidity 5-95% (non-condensing); IP20 protection rating (cabinet-mounted)
-
Mechanical Features: 140mm×110mm×40mm (L×W×H); Weight ~0.5kg; DIN rail mount; LED status indicators per channel
-
Certifications: CE, UL certified; Compliant with IEC 61131-3 and SIL 2 safety standards
-
Special Functions: Supports cascade control, ratio control, and sleep mode for energy saving in low-load scenarios
Recommended ABB Products
-
ABB PM864AK01 3BSE018161R1: AC 800M CPU module that coordinates with MPRC086444-005 for large-scale system control.
-
ABB XVC724BE101 3BHE009017R0101: High-precision analog input module that provides accurate sensor data to MPRC086444-005.
-
ABB AO835 3BDH000056R1: Analog output module that enhances MPRC086444-005’s capacity to drive multiple actuators.
-
ABB CI854A 3BSE022363R1: Profibus DP communication module that extends MPRC086444-005’s network connectivity.
-
ABB REF615 1MRK504153-BEN: Protection relay that uses MPRC086444-005’s signals to trigger over-limit safety actions.
-
ABB UFC911B108 3BHE037864R0108: Digital I/O module that complements MPRC086444-005 for mixed-signal control.
-
ABB ACS510: Frequency converter that works with MPRC086444-005 to achieve energy-efficient constant-pressure water supply.
-
ABB PPD113B03-26-100110 3BHE023584R2634: High-integration digital I/O module that expands MPRC086444-005’s monitoring points.
-
ABB XO08R2 1SBP260109R1001: Compact digital output module that drives auxiliary devices based on MPRC086444-005’s commands.
-
ABB PS860 3BSE008545R1: Redundant power supply module that ensures uninterrupted operation of MPRC086444-005.
