Introduction to ABB NSSM01
NSSM01 Product Overview
The ABB NSSM01 is a versatile serial communication and data storage module belonging to the Bailey Superloop product series, specifically engineered for seamless data transmission and secure information management in industrial automation systems. As a dual-functional component integrating communication and storage capabilities, it adopts GFSK modulation technology to achieve reliable data transmission up to 3000 meters (line-of-sight) at 490 MHz metering band, while its built-in solid-state flash memory ensures secure storage of critical operational data. Supporting multiple industrial protocols (Profinet, Modbus TCP, EtherCAT) and interfaces (TTL, RS-232, RS-485, 10/100 Base-TX Ethernet), it serves as a key connectivity hub in manufacturing lines, power plant energy management systems, and robot control networks. Its compact design (170mm×95mm×30mm) allows easy installation in space-constrained cabinets, while the semi-duplex working mode enables automatic and fast data send/receive switching.
NSSM01 Technical Specifications
-
Product Model: NSSM01
-
Product Type: Serial Communication & Data Storage Module
-
Series Affiliation: ABB Bailey Superloop Series
-
Core Functions: Multi-protocol data transmission, remote communication, critical data storage, device connectivity management
-
Communication Technology: GFSK modulation; Carrier frequency 490 MHz (metering band)
-
Transmission Performance: Reliable distance up to 3000m (line-of-sight); Interface rate 1200-38400 bps
-
Channel & Interface: 8 communication channels; TTL/RS-232/RS-485 serial interfaces; 10/100 Base-TX Ethernet port
-
Supported Protocols: Profinet, Modbus TCP, EtherCAT, Ethernet/IP, DeviceNet
-
Working Mode: Semi-duplex; Automatic data send/receive switching
-
Storage Feature: Solid-state flash memory; Low power consumption; High durability
-
Power Supply: DC 24V ±10%; Power consumption ≤5W
-
Operating Environment: Temperature -20°C to +60°C; Humidity 5-95% (non-condensing); Protection rating IP20
-
Mechanical Features: Compact design; Dimensions 170mm×95mm×30mm (L×W×H); Weight ~0.1kg
-
Compatibility: ABB industrial automation systems; ABB IMDSM04 module; Third-party devices via standard protocols
-
Certifications: CE, UL certified; Complies with IEC industrial communication standards
