Introduction to ABB NTR002-A
NTR002-A Product Overview
The ABB NTR002-A is a high-precision temperature measurement and transmission instrument, specifically designed for accurate temperature monitoring in industrial process control systems. It serves as a critical link between temperature sensors (such as thermocouples and RTDs) and upper-level control units, converting detected temperature signals into standard industrial output signals for reliable data transmission and process regulation. Equipped with advanced signal processing technology, the instrument effectively suppresses electromagnetic interference, ensuring stable and accurate measurement performance even in harsh industrial environments with voltage fluctuations and environmental disturbances. Featuring a compact and rugged design, it supports flexible installation methods suitable for various industrial sites, including manufacturing plants, petrochemical facilities, and power generation stations.
NTR002-A Technical Specifications
-
Product Model: NTR002-A
-
Product Type: Industrial Temperature Measurement and Transmission Instrument
-
Core Functions: Temperature signal acquisition, signal conversion and transmission, anti-interference processing, fault self-diagnosis
-
Input Compatibility: Compatible with various thermocouple (J, K, T, E, R, S, B) and RTD (Pt100, Pt1000) sensors
-
Output Signal: Standard 4-20mA analog output; Optional HART communication protocol for remote configuration and monitoring
-
Measurement Accuracy: ±0.1% of full scale; High-precision signal conversion ensures reliable temperature data
-
Power Supply: 24V DC ±10%; Loop-powered design for energy efficiency, power consumption ≤5W
-
Operating Environment: Temperature range: -20°C to +60°C; Humidity: 5-95% (non-condensing); Complies with IEC 61000-6-2/4 EMC standards
-
Protection Class: IP65; Dust-tight and water-resistant design suitable for on-site installation
-
Mechanical Dimensions: 45mm × 145mm × 110mm; Weight: Approximately 0.25kg
-
Installation Method: DIN rail mounting or panel mounting; Tool-free wiring terminals for easy installation
-
Safety Features: Overvoltage protection, short-circuit protection, reverse polarity protection
-
Certifications: CE, UL compliant; Suitable for global industrial process control applications
