Introduction to ABB O3EHa HENF315087R2
HENF315087R2 Product Overview
The ABB O3EHa HENF315087R2 is a high-performance modular analog input control module, specifically designed for distributed control systems (DCS) and programmable logic controllers (PLC) in industrial automation. As a key product of ABB’s O3EHa series, it integrates precise signal acquisition, reliable data processing, and rugged hardware design, specializing in collecting and processing analog signals from field sensors (such as temperature, pressure, and flow sensors). The module supports HART communication protocol, enabling seamless integration with HART field devices and upper-level control systems. Featuring excellent anti-interference and anti-vibration performance, it is engineered to operate stably in harsh industrial environments like petrochemical, power generation, and mining industries. Widely applied in process control, equipment monitoring, and energy management systems, the O3EHa HENF315087R2 enhances data acquisition accuracy and system reliability, supporting users in achieving refined industrial process management.
HENF315087R2 Technical Specifications
-
Product Model: O3EHa HENF315087R2
-
Product Type: Industrial Analog Input Control Module
-
Core Functions: Multi-channel analog signal acquisition (4-20 mA, 0-20 mA), HART communication support, signal filtering and processing, fault diagnosis (open/short circuit monitoring), loop supervision, hot-swapping capability, field circuit isolation
-
Power Supply: 24 VDC powered via Modulebus; Transmitter power current limit: 30 mA; Low power consumption design
-
Input Specifications: Supports 2-wire or 4-wire external powered field devices; 16-bit A/D converter resolution; Hardware filter rise time: 1 ms; Configurable software filter
-
Communication Interface: Supports HART (Application Layer Revision 7), including HART pass-through and cyclic reading of up to 2 HART device variables; Compatible with Modbus, PROFIBUS protocols
-
Isolation Performance: Current isolation between channels; Electronic current limiting for all SCMs
-
Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -40°C to +125°C; Suitable for hazardous areas; Anti-vibration and anti-interference
-
Mechanical & Installation: Modular design; Mechanical keying to prevent wrong module insertion; Locking slider for power shutdown before disassembly; Supports hot-swapping; LED indicators for operation status
-
Compatibility: Fully compatible with ABB DCS and PLC systems; Seamless integration with HART field devices
-
Protection & Diagnosis: Anti-wrong wiring protection; Hardware error monitoring, communication supervision; Under-range/over-range detection; Internal power supervision
Recommended ABB Same-Series Models
-
ABB O3EHa HENF315088R2: Enhanced analog input module with extended channel count, suitable for large-scale signal acquisition scenarios
-
ABB O3EX HENF315845R2: High-performance industrial control module, supporting multiple communication protocols and 16 digital I/O ports
-
ABB O3EId HENF452777R3: DCS PLC module with multi-protocol support, ideal for process control and IoT integration
-
ABB O3EC HENF442581R1: Industrial control module with configurable I/O, supporting dual Ethernet communication
-
ABB O3EGb HENF315118R2: Multi-protocol control module, facilitating seamless integration with diverse automation systems
-
ABB P5EAa HENF206350R2: Digital control module with PID function, specialized in precise process parameter regulation
-
ABB INPM01: Process monitoring module, enabling real-time collection and analysis of industrial process parameters
-
ABB INPD01: High-precision data acquisition module, focusing on analog and digital signal processing
-
ABB O3EC HENF442582R1: Industrial control module with extended I/O channels, for complex process control
-
ABB AC500-eCo V3: Compact PLC module with Ethernet ports, supporting IoT protocols for smart factories
-
ABB P5EAa HENF206351R2: Enhanced digital control module, adaptable to complex industrial process requirements
-
ABB AC500-S: High-performance PLC module with floating-point unit, supporting advanced motion control
-
ABB O3EHa HENF315089R2: Analog input module with enhanced HART functions, suitable for smart field device integration
