Introduction to ABB P3EB HENF315223R1
HENF315223R1 Product Overview
The ABB P3EB HENF315223R1 is a high-performance process control signal module belonging to ABB’s Compact product series, specifically engineered for precise signal conditioning and conversion in industrial process automation systems. It serves as a critical link between field sensors/transmitters and upper-level control systems (such as AC 800M controllers and DCS), responsible for converting weak analog signals from key process parameters like temperature, pressure, and flow into standard industrial signals that can be accurately recognized and processed by controllers. Equipped with advanced industrial-grade signal processing technology and excellent anti-interference performance, the module maintains stable operation in harsh industrial environments with electromagnetic interference and voltage fluctuations, which is essential for ensuring continuous and reliable operation of process industries such as petrochemical, power generation, and water treatment.
HENF315223R1 Technical Specifications
-
Product Model: P3EB HENF315223R1
-
Product Type: Industrial Process Control Signal Module (Compact Series)
-
Core Functions: Analog signal conditioning, signal conversion, process parameter monitoring, data transmission, fault self-diagnosis
-
Input Signal: Supports multiple analog input types (4-20mA, 0-10V); Compatible with temperature, pressure, flow sensors
-
Output Signal: Standard industrial analog output (4-20mA); High conversion accuracy with error ≤0.1% FS
-
Communication Capability: Supports Modbus, PROFIBUS DP industrial protocols; Seamless integration with ABB AC 800M/DCS systems
-
Power Supply: 24V DC ±10%; Power consumption ≤6W
-
Isolation Performance: Input-output isolation voltage ≥1000V AC; Effectively suppresses electromagnetic interference
-
Operating Environment: Temperature range: -25°C to +65°C; Humidity: 5-95% (non-condensing); Vibration resistance compliant with IEC 61000-6-2/4
-
Mechanical Dimensions: 35mm × 105mm × 120mm; Weight: Approximately 0.19kg
-
Safety Features: Overvoltage protection, short-circuit protection, reverse polarity protection
-
Installation Method: 35mm DIN rail mounting; Tool-free wiring terminals for easy maintenance
-
Certifications: CE, UL, IEC 61131-2 compliant; Suitable for global industrial process automation applications
