ABB PFSK163 3BSE016323R3 Product Introduction
1. Product Overview
The ABB PFSK163 3BSE016323R3 is a high-integrity industrial programmable safety controller belonging to ABB’s SafePLC series, engineered for safety instrumented systems (SIS) in high-risk industries. It serves oil & gas, petrochemicals, power generation, and manufacturing sectors—focusing on executing safety interlocks (e.g., emergency shutdown, overpressure protection) and fault detection to prevent hazardous incidents, aligning with global safety standards like IEC 61508.
Integrating dual-core redundancy and SIL 3 compliance, it ensures reliable operation even in harsh industrial environments. Compatibility with ABB’s safety I/O modules and standard communication protocols enables seamless integration into existing automation ecosystems, making it a trusted choice for mission-critical safety control.
2. Technical Parameters (Table)
|
Category
|
Specification
|
|
Device Type
|
Dual-core programmable safety controller (for SIS)
|
|
Safety Integrity Level (SIL)
|
SIL 3 (IEC 61508); Suitable for safety functions up to SIL 3
|
|
Processing Performance
|
Dual 32-bit ARM Cortex-M7 cores; Instruction execution speed: ≥2 million steps/sec
|
|
Memory
|
Program memory: 4 MB; Data memory: 2 MB; Non-volatile memory: 1 MB (for fault logging)
|
|
I/O Expansion
|
Supports up to 32 ABB safety I/O modules (digital/analog/temperature) via SafeBus
|
|
Communication Ports
|
2×Ethernet (Modbus TCP/IP, Profinet); 1×RS485 (Modbus RTU); 1×SafeBus (for safety I/O)
|
|
Power Supply
|
24 V DC (18–32 V DC); Redundant power input; Power consumption: ≤18 W (operating)
|
|
Environmental Ratings
|
Operating temperature: -10°C to +60°C (14°F to +140°F); Storage temperature: -20°C to +70°C (-4°F to +158°F); Humidity: 5%–95% (non-condensing); Protection class: IP20 (enclosure)
|
|
Programming Software
|
ABB SafePLC Configurator (supports IEC 61131-3 safety languages: LD, FBD, ST)
|
|
Mechanical Design
|
Mounting: DIN rail (35 mm); Housing material: Flame-retardant polycarbonate; Dimensions: 150 mm (W) × 120 mm (H) × 80 mm (D); Weight: ~650 g (1.43 lbs)
|
|
Certifications
|
CE; UL 61010-1; CSA C22.2 No. 61010-1; ATEX Zone 2; IECEx; RoHS compliant
|
3. Product Specifications & Features
3.1 Core Specifications
The ABB PFSK163 3BSE016323R3 is optimized for safety-critical control, with dual-core redundancy ensuring no single-point failure—critical for SIL 3 applications (e.g., refinery emergency shutdown systems). Its ability to connect 32 safety I/O modules supports large-scale SIS (e.g., monitoring 100+ safety sensors across a chemical plant), while non-volatile memory logs up to 1000 fault events for post-incident analysis.
Dual Ethernet ports enable separate safety and non-safety communication (e.g., Profinet for safety I/O, Modbus TCP/IP for HMI monitoring), preventing cross-interference. The 24 V DC redundant power input further enhances reliability, ensuring continuous operation even if one power source fails.
3.2 Key Features
- SIL 3 Compliance: Meets the highest safety standards for high-risk industries, ensuring safety functions are executed reliably.
- Dual-Core Redundancy: Eliminates single-point failures, minimizing unplanned downtime in safety-critical systems.
- Scalable I/O Expansion: Supports up to 32 safety I/O modules, adapting to small-to-large SIS configurations.
- Dedicated Safety Bus: SafeBus ensures secure, real-time communication with safety I/O, avoiding data corruption.
- Intuitive Programming: ABB SafePLC Configurator simplifies safety logic development, with built-in tools for SIL verification.
4. Other ABB Safety Automation Products
ABB offers complementary safety controllers and I/O modules for diverse SIS needs:
- ABB PFSK103 3BSE016322R1: Compact safety controller (SIL 2) for small-scale applications (e.g., standalone machine safety).
- ABB PFSK203 3BSE016324R1: High-performance controller (SIL 3, 4-core) for large industrial SIS (e.g., power plant boiler protection).
- ABB PFDI162 3BSE016331R1: 16-channel digital input module (SIL 3) for safety sensor connection (e.g., emergency stop buttons).
- ABB PFDO162 3BSE016332R1: 16-channel digital output module (SIL 3) for safety actuators (e.g., shutdown valves).
- ABB PFAI82 3BSE016333R1: 8-channel analog input module (SIL 3) for safety-related process monitoring (e.g., pressure, temperature).
