Introduction to ABB PP846A 3BSE042238R2

Name: 3BSE042238R2 ABB PP846A
SKU: 5770
Price: 500.00 USD
Availability: InStock

3BSE042238R2 Product Overview

The ABB PP846A 3BSE042238R2 is a high-performance advanced operator panel belonging to ABB’s Panel 800 series, specifically designed to serve as a reliable human-machine interface (HMI) in industrial automation systems. It acts as a critical bridge between operators and automated equipment, enabling real-time monitoring and control of industrial processes, machinery, and systems across manufacturing, chemical, water treatment, and power generation sectors. A key feature of this panel is its 10.4-inch high-resolution TFT color display with 800×600 pixels, which delivers clear graphical interfaces and multi-language support for easy operation even in low-light environments. Equipped with 10 customizable function keys and a responsive touchscreen (available in resistive or capacitive type), it allows operators to quickly access frequently used functions and adjust process parameters efficiently.

PP846A 3BSE042238R2

3BSE042238R2 Technical Specifications

Product Model: PP846A 3BSE042238R2
Product Type: Advanced Operator Panel (HMI) of ABB Panel 800 Series
Core Functions: Real-time process monitoring, equipment status display, parameter setting, alarm notification, data logging and trend analysis
Display Performance: 10.4-inch TFT color display; Resolution 800×600 pixels; Supports 64K colors; Multi-language display
Touchscreen & Operation: Resistive or capacitive touchscreen; 10 customizable function keys; Response time <50μs
Memory Configuration: 2GB RAM; 16GB Flash Memory
Communication Capability: Supported protocols include Ethernet, EtherCAT, RS-232, RS-422/485; Seamless connection with PLC/DCS
Power Supply: 24V DC ±20% (19.2V DC – 28.8V DC); Power consumption ≤1.6W
Protection Features: Protection rating IP65 (some models IP66); ESD protection; Vibration resistance
Operating Environment: Temperature range -40°C to +85°C; Humidity 5-95% (non-condensing)
Mechanical Dimensions: 22.9mm (W) × 99.3mm (H) × 114.5mm (D); Panel mount
Weight: Approximately 3.115kg
Design Feature: Modular design, supporting flexible function expansion and easy maintenance

Recommended ABB Products

ABB AC500 PLC Series: Modular programmable logic controller that works with PP846A for precise industrial process control in manufacturing lines.
ABB 800xA DCS: Distributed control system that integrates PP846A to enable centralized monitoring of large-scale chemical and power plants.
ABB PP865 Panel: 15-inch large-screen operator panel, an upgraded version of PP846A, suitable for complex process visualization in water treatment facilities.
ABB ACS880 Inverter: High-performance frequency converter that communicates with PP846A for motor speed regulation and energy saving.
ABB CM578 Communication Module: Extends PP846A’s communication capabilities, enabling seamless data exchange in distributed automation systems.
ABB TP810 Touch Panel: Compact 10-inch touch panel, compatible with PP846A, ideal for small-scale machinery control in automotive component production.
ABB 3BSE036369R1 CPU Module: Core processing unit for ABB PLCs, collaborating with PP846A to enhance real-time data processing efficiency.
ABB SafeMove2 Safety Controller: Integrates with PP846A to provide safe and reliable control for industrial robot systems in electronics manufacturing.
