Introduction to ABB PPC905AE101 3BHE014070R01014
The ABB PPC905AE101 (order number: 3BHE014070R01014) is a high-precision excitation control module, celebrated as the “magnetic field regulation core” for synchronous generators in power generation systems. As a key component of ABB’s Unitrol® series excitation systems, it integrates advanced PID control algorithms, multi-channel signal processing, and dual-redundancy design, specializing in regulating the generator’s excitation current to maintain stable terminal voltage and optimize reactive power distribution. This module is widely applied in thermal power plants, hydropower stations, and industrial self-owned generators, effectively enhancing the generator’s grid-connection stability and anti-interference capability. Its industrial-grade design features 2500Vrms galvanic isolation between analog and digital circuits, resisting strong electromagnetic interference from generator sets, while the operating temperature range of -25°C to +70°C adapts to harsh on-site environments.
3BHE014070R01014 Key Technical Specifications
-
Device Type: High-precision excitation control module (Unitrol® series supporting component)
-
Core Functions: Generator terminal voltage regulation, reactive power control, excitation current limiting, fault protection
-
Compatible Systems: ABB Unitrol 6000 excitation system, 800xA DCS, Symphony®Plus control platform
-
Control Performance: Voltage regulation accuracy ±0.2% of rated value; response time ≤ 10ms for grid disturbance
-
Input/Output Configuration: 8-channel analog input (4-20mA); 6-channel analog output (0-10V/4-20mA); 16 digital I/O points
-
Power Supply: 24V DC (redundant input); input range 18-36V DC; typical power consumption ≤ 25W
-
Communication Interface: RS485, Modbus RTU; supports IEC 61850 protocol for substation integration
-
Redundancy Feature: Dual-module hot standby; automatic switchover time < 5ms without disturbance
-
Operating Environment: Temperature -25°C to +70°C; humidity 5-95% (non-condensing); storage temp -40°C to +85°C
-
Physical Specifications: 180mm × 120mm × 50mm; weight ~1.5kg; rack-mounted (compatible with Unitrol chassis)
-
Protection Features: Overexcitation, underexcitation protection; overcurrent, overtemperature alarm; voltage loss detection
-
Certifications: CE, UL compliant; RoHS certified; meets IEC 61131-3 and IEEE 421.5 standards
Recommended ABB Related Models
-
ABB PPC907AE101 3BHE014072R0101: Advanced excitation control module, supports multi-generator parallel control in hydropower stations
-
ABB PCD235B1101 3BHE032025R1101: Excitation power module, provides stable current output for PPC905AE101
-
ABB PM864AK01 3BSE018161R1: AC 800M CPU controller, processes excitation data from PPC905AE101 in integrated DCS
-
ABB CI858K01 3BSE018135R1: Multi-protocol communication module, transmits PPC905AE101’s data to remote SCADA systems
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes PPC905AE101’s excitation parameters and fault status
-
ABB AI845 3BSE023675R1: High-precision analog input module, expands PPC905AE101’s sensor signal collection
-
ABB AO810 3BSE032453R1: 8-channel analog output module, executes auxiliary control based on PPC905AE101’s commands
-
ABB REF620: Digital relay protector, safeguards PPC905AE101 and associated generator equipment
-
ABB SYN5202-0277 3BHB006715R0277: Grid-connection synchronization module, collaborates with PPC905AE101 for generator parallel operation
-
ABB GVC736BE101 3BHE019719R0101: Gate driver module, complements PPC905AE101 in high-power excitation systems
-
ABB UFC762AE101 3BHE006412R0101: High-precision analog input module, collects generator voltage data for PPC905AE101
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time data interaction with PPC905AE101
-
ABB AC500 PLC: Compact controller, pairs with PPC905AE101 for small-scale industrial generator control
-
ABB ACS880-07: Medium-voltage frequency converter, auxiliary drive for generator auxiliary systems
-
ABB 3BHB013085R0001 5SHY3545L0009: High-power IGCT module, supports PPC905AE101 in large generator excitation systems
-
ABB PM866K01 3BSE050200R1: High-end AC 800M CPU, handles complex excitation control logic for PPC905AE101 View more …..
