Introduction to ABB PU515A 3BSE032401R1

Name: 3BSE032401R1 ABB PU515A redundant power supply module
SKU: 5831
Price: 1399.00 USD
Availability: InStock

3BSE032401R1 Product Overview

The ABB PU515A (order code: 3BSE032401R1) is a high-stability redundant power supply module exclusively engineered for ABB’s AC 800M distributed control system (DCS), serving as the “energy core” to ensure continuous and reliable power for controllers, I/O modules, and communication units. Designed with dual-channel redundant architecture, it automatically switches between main and standby power paths within microseconds when a power failure or voltage fluctuation occurs, effectively preventing system downtime caused by power interruptions—critical for mission-critical applications in petrochemical, power generation, and pharmaceutical industries. Unlike conventional power modules, it integrates intelligent load balancing and overcurrent protection, dynamically allocating power resources between AC 800M components and triggering alarms for abnormal loads without shutting down the entire system.

3BSE032401R1 PU515A

3BSE032401R1 Technical Specifications

Product Model: PU515A (Order Code: 3BSE032401R1)
Product Type: Redundant Power Supply Module for AC 800M DCS
Series Affiliation: ABB AC 800M Power Supply Series
Core Functions: System power supply, redundant power management, load balancing, overcurrent/overvoltage protection
Input Specifications: AC 85-264V (47-63Hz); Input current ≤5A
Output Specifications: DC 24V ±0.5%; Rated output current 15A; Peak output current 20A (10s)
Redundancy Performance: Dual-channel redundant design; Automatic switchover time <5ms; Redundant status synchronization
Protection Features: Overcurrent protection (adjustable threshold), overvoltage protection (28V±0.5V), undervoltage protection (19V±0.5V), short-circuit protection
Conversion Efficiency: Up to 92% at full load
Monitoring Functions: Output voltage/current real-time monitoring; Fault status signal output (dry contact)
Operating Environment: Temperature -10°C to +60°C; Humidity 5-95% (non-condensing); Protection rating IP20
Mechanical Features: Rack mount (fits AC 800M cabinet); Dimensions 124mm×74mm×100mm (L×W×H); Weight ~1.2kg
Compatibility: Seamless integration with AC 800M controllers (PM864/PM865), CI85x communication modules, and S800 I/O modules
Certifications: CE, UL, IEC 61010 certified; Compliant with IEC 61131-2 industrial standards
