Introduction to ABB SYN5202-0277 3BHB006715R0277
ABB SYN5202-0277 (order number: 3BHB006715R0277) is a highly reliable dual channel industrial grid synchronization module, known as the “grid coordination core” for power generation systems and industrial power grids. As ABB Synchrotact ® The flagship product of the 5 series. Its robust industrial grade design features a 1500Vrms electrical isolation function, which can resist electromagnetic interference from high-voltage power equipment, and a working temperature range of -25 ° C to+70 ° C can adapt to harsh on-site environments. Equipped with rich communication interfaces and user-friendly configuration platform, it supports seamless integration with ABB AC 800M DCS and third-party control systems. The built-in overvoltage, undervoltage, and overclocking protection mechanisms further enhance the safety of grid connected operation.
3BHB006715R0277 Key Technical Specifications
-
Device Type: Dual-channel industrial grid-connection synchronization module (Synchrotact®5 series)
-
Core Functions: Automatic voltage/frequency/phase matching, grid parameter monitoring, fault protection, remote control
-
Application Scope: Wind/photovoltaic power plants, industrial self-owned power stations, substations, generator grid-connection
-
Measurement Performance: Voltage measurement range 0-500V AC; measurement accuracy 0.2% FS; response time ≤ 1ms
-
Input/Output Configuration: 24 I/O points; 4-channel 4-20mA control output (excitation/inverter regulation); output accuracy 0.5% FS
-
Power Supply: 24V DC or 110/220V AC; typical power consumption ≤ 15W
-
Communication Interface: RS485, Modbus RTU, EtherNet/IP, PROFINET; supports IEC 61850 protocol
-
Redundancy Feature: Dual-channel design; automatic switchover without operation interruption
-
Operating Environment: Temperature -25°C to +70°C; humidity 5-95% (non-condensing); storage temp -40°C to +85°C
-
Physical Specifications: 220mm × 160mm × 40mm; weight ~1.2kg; 35mm DIN rail mounting
-
Protection Features: Overvoltage, undervoltage, overfrequency, underfrequency, excessive phase difference protection
-
Certifications: CE, UL compliant; RoHS certified; meets IEC protection standards and grid-connection regulations
Recommended ABB Related Models
-
ABB SYN5201-0100 3BHB006714R0100: Single-channel synchronization module, cost-effective option for small-scale photovoltaic systems
-
ABB SYN5302 3BHB006716R0101: High-end multi-functional synchronization module, ideal for large wind power bases
-
ABB PM864AK01 3BSE018161R1: AC 800M CPU controller, processes grid-connection data from SYN5202-0277 in integrated DCS
-
ABB CI858K01 3BSE018135R1: Multi-protocol communication module, transmits SYN5202-0277’s data to remote SCADA systems
-
ABB TP854 3BSE025349R1: 7-inch HMI, visualizes SYN5202-0277’s synchronization parameters and fault alerts on-site
-
ABB AI810 3BSE032456R1: 8-channel analog input module, expands SYN5202-0277’s grid parameter collection capability
-
ABB DO810 3BSE032452R1: 16-channel digital output module, executes grid-connection switch control based on SYN5202-0277’s commands
-
ABB REF620: Digital relay protector, collaborates with SYN5202-0277 to safeguard generator and grid equipment
-
ABB ACS880-07: Medium-voltage frequency converter, auxiliary drive paired with SYN5202-0277 in industrial power systems
-
ABB UFC762AE101 3BHE006412R0101: High-precision analog input module, collects high-accuracy voltage data for SYN5202-0277
-
ABB PCD235B1101 3BHE032025R1101: Excitation control module, integrates SYN5202-0277’s signals for generator parameter regulation
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time data interaction with SYN5202-0277
-
ABB AC500 PLC: Compact controller, pairs with SYN5202-0277 for small-scale industrial self-owned power stations
-
ABB GVC736BE101 3BHE019719R0101: Gate driver module, complements SYN5202-0277 in inverter grid-connection systems
-
ABB SYNCHROTACT 6: Next-generation synchronization device, compatible with SYN5202-0277 for system upgrade
-
ABB ACS6000: Medium-voltage converter, core platform integrating SYN5202-0277 for large generator grid-connection View more …..
