Introduction to ABB TP854 3BSE025349R1
The ABB TP854 3BSE025349R1 is a high-performance industrial Human-Machine Interface (HMI), serving as a critical “interaction bridge” between operators and automation systems. As a key product in ABB’s ControlMaster HMI series, it features a vivid display and precise touch control to visualize complex process data and enable intuitive operation. This HMI excels in presenting real-time parameters (such as temperature, pressure, and equipment status), supporting parameter configuration, fault alarming, and data recording. It is widely applied in industries including power generation (turbine control rooms), petrochemicals (reaction vessel monitoring), metallurgy (blast furnace operations), and automotive manufacturing (welding robot control). Its robust design with IP65 front-panel protection resists dust and liquid splashes, while the glove-friendly resistive touchscreen adapts to harsh industrial environments. Seamless compatibility with ABB AC800M DCS and third-party PLCs simplifies system integration, significantly enhancing operational efficiency and reducing troubleshooting time.
3BSE025349R1 Key Technical Specifications
-
Device Type: Industrial resistive touchscreen HMI
-
Display Performance: 7-inch TFT true-color screen; 800×480 resolution; 64K color depth
-
Touch Function: Resistive touch technology; supports gloved operation; response time ≤10ms
-
Communication Interface: Ethernet (RJ45), RS232, RS485; supports PROFINET, MODBUS, PROFIBUS-DP/V1
-
Storage Configuration: 128MB RAM; 512MB Flash memory (supports historical data storage)
-
Power Supply: 24V DC (nominal); input range 18-30V DC; power consumption ≤10W
-
Operating Environment: Temperature -10°C to +60°C; humidity 5-95% (non-condensing)
-
Physical Specifications: 170mm × 128mm × 55mm; weight 0.5kg; panel-mounted design
-
Protection Level: Front panel IP65; rear IP20; EMC compliance with IEC 61000-6-2
-
Software Compatibility: Supports ABB Panel Builder 600; multi-language interface (English, German, Spanish)
-
Certifications: CE, UL, RoHS, WEEE compliant; meets IEC 61131-2 standards
-
Special Features: Real-time alarm pop-up; trend graph display; offline data recording
Recommended ABB Related Models
-
ABB CP635 3BSE050154R1: 7-inch wide-screen HMI with 800×480 resolution, ideal for small-scale packaging lines
-
ABB CP650 3BSE050156R1: 10.4-inch touchscreen HMI, suitable for large power plant control rooms
-
ABB CP675 3BSE050158R1: 15-inch high-resolution HMI, designed for complex process control in petrochemical plants
-
ABB CP620 3BSE050152R1: 4.3-inch compact HMI, cost-effective for solar-powered remote monitoring stations
-
ABB PM866 3BSE050200R1: AC 800M CPU controller, perfectly matches TP854 for integrated control systems
-
ABB CI854A 3BSE022469R1: PROFIBUS communication module, enhances TP854’s connectivity with field devices
-
ABB CP630-WEB 3BSE050153R2: 5.7-inch HMI with web access, supports remote monitoring of food processing lines
-
ABB TP855 3BSE025350R1: Enhanced version of TP854 with 10.4-inch screen, for high-precision metallurgy control
-
ABB AI810 3BSE032456R1: 8-channel analog input module, feeds precise sensor data to TP854
-
ABB DO810 3BSE032452R1: 16-channel digital output module, executes control commands from TP854
-
ABB CI871AK01 3BSE092693R1: High-speed PROFIBUS module, ensures real-time data transmission with TP854
-
ABB PCD237A101 3BHE028915R0101: Distributed I/O module, expands TP854’s monitoring capacity in oilfield systems View more …..
