Introduction to ABB UFC718AE01 HIEE300936R0101
The ABB UFC718AE01 (order number: HIEE300936R0101) is a high-performance integrated control module, renowned as the “versatile control hub” in modern industrial automation systems. As a flagship product of ABB’s UFC700 series, it integrates advanced data acquisition, motion control, and multi-protocol communication capabilities, supporting position, speed, and process loop control to adapt to diverse scenarios—from robot coordination in automotive assembly lines to generator monitoring in power plants, and chemical process regulation in petrochemical reactors . Powered by a high-speed 32-bit processor, this module ensures real-time response to complex control commands with microsecond-level processing latency. Its robust design features industrial-grade EMC protection (compliant with IEC 61000-4 standards) and wide environmental adaptability, maintaining stable operation amid strong electromagnetic interference and temperature fluctuations .
HIEE300936R0101 Key Technical Specifications
-
Device Type: Multi-functional industrial control module (motion control + process control)
-
Core Processor: 32-bit high-performance processor; processing latency ≤ 300μs
-
I/O Configuration: 32 I/O points (16 digital inputs, 8 digital outputs, 8 analog inputs); supports 4-20mA/0-10V signals
-
Control Modes: Position control, speed control, torque control, multi-loop process control; switchable per application
-
Communication Protocols: EtherCAT, CANopen, Modbus RTU, PROFIBUS DP, Ethernet/IP; dual redundant Ethernet ports
-
Power Supply: 24V DC (nominal); compatible with 18-36V DC input range; typical power consumption ≤ 12W
-
Output Performance: Pulse output frequency up to 200kHz; analog output precision ±0.1% FS
-
Memory Capacity: 512KB program memory; 1MB data storage memory; supports SD card expansion
-
Operating Environment: Temperature -20°C to +60°C; humidity 5-95% (non-condensing); vibration resistance 5g (10-500Hz)
-
Physical Specifications: 150mm × 100mm × 40mm; net weight 0.4kg; 35mm DIN rail mounting; IP20 protection level
-
Protection Features: Overcurrent, overvoltage, undervoltage, overheating protection; encoder fault detection; wire breakage alarm
-
Certifications: CE, RoHS, UL compliant; meets IEC 61131-2 industrial control standards
