Bently Nevada 135137-01 Product Overview
Bently Nevada 135137-01 Product Introduction
Bently Nevada 135137-01 is a dedicated position monitoring I/O module compatible with the 3500 series machinery protection and condition monitoring systems. Designed to work with the 3500/45 monitoring unit, it delivers precise real-time measurement of mechanical position parameters for critical rotating equipment. The module processes sensor input signals to capture subtle positional changes of machine shafts and components, supporting accurate condition tracking and threshold-based alarm triggering. It features reliable signal processing and stable data output, enabling seamless integration with upper monitoring platforms for centralized data management. Built with industrial-grade rugged design, it resists field electromagnetic interference and supports long-term continuous operation in power, petrochemical and heavy industrial scenarios.
Bently Nevada 135137-01 Technical Specifications
-
Product Model: 135137-01 (3500 Series Position Monitoring I/O Module)
-
Matched Device: Perfectly compatible with 3500/45 position monitor module
-
Core Function: Mechanical position signal acquisition, conditioning and data transmission
-
Communication Protocol: Supports standard RS-485 industrial communication
-
Signal Performance: Low noise signal processing for high-precision measurement results
-
Installation Type: Standard rack-mounted structure for 3500 system chassis
-
Operating Temperature: -30°C to +65°C for standard industrial cabinet environments
-
Environmental Resistance: Excellent anti-interference capability for harsh field conditions
-
Operational Stability: Supports 24/7 continuous industrial monitoring operation
-
Software Adaptation: Fully compatible with Bently Nevada System 1 monitoring software
Recommended Bently Nevada Same-Series Models
-
3500/15: Redundant power supply module providing stable continuous power for full system racks
-
3500/20: Rack interface module for system configuration and internal rack unified management
-
3500/22: Transient data interface module for high-speed waveform capture and network data upload
-
3500/25: Keyphasor module for shaft phase reference and rotational timing signal collection
-
3500/32M: Four-channel relay module for on-site alarm and safety interlock signal output
-
3500/34: High-density 16-channel relay module for multi-point protection signal expansion
-
3500/40M: Multi-functional module for vibration and displacement condition monitoring
-
3500/42M: High-precision seismic module for mechanical vibration fault diagnosis and early warning
-
3500/53: Overspeed detection module for real-time rotational speed monitoring and emergency protection
-
128229-01: Multi-channel I/O module for field sensor signal acquisition and processing
-
133819-01: Temperature input module for real-time thermal parameter collection of equipment
-
133396-01: System expansion module for rack resource optimization and auxiliary data processing
