B&R 4PPC30.0702-23C001 Product Introduction
B&R 4PPC30.0702-23C001 is an integrated industrial power panel belonging to B&R’s Power Panel C series, combining HMI functionality with a built-in controller for industrial automation systems. It features a compact, maintenance-free design with no hard drive, fan or battery, making it ideal for harsh industrial environments. Equipped with a high-performance ARM Cortex-A8 processor and a user-friendly touch screen, this module enables seamless human-machine interaction, real-time data processing and reliable communication with field devices. Its front panel boasts IP65 protection, while passive cooling ensures stable operation in various industrial settings such as manufacturing, packaging and process control, supporting efficient equipment monitoring and control.
B&R 4PPC30.0702-23C001 Technical Specifications
-
Product Model: 4PPC30.0702-23C001 (B&R)
-
Product Type: Integrated Industrial Power Panel (Power Panel C Series)
-
Processor: ARM Cortex-A8, 1 GHz clock frequency
-
Memory: 256 MB DRAM, 512 MB flash memory (10-year data retention)
-
Display: 7.0″ TFT color screen, 800 x 480 WVGA resolution, 16.7 million colors
-
Touch Screen: AMT type, analog resistive technology
-
Backlight: LED, typical brightness 500 cd/m², 50,000-hour half-brightness life
-
Cooling Method: Passive cooling
-
Buttons: Reset button (no power button), with built-in buzzer
-
Status Indicators: Supply voltage OK, operating state, module status, Ethernet, CAN Rx/Tx, RS485 Rx/Tx
-
Certifications: CE, UKCA, cULus E115267 (industrial control equipment)
-
Operating Temperature: -10°C to +55°C (typical industrial range)
-
Protection Class: IP65 (front panel)
