Controller 3BHE006373R0101 XVC769AE101 ABB

ABB Product: 3BHE006373R0101 XVC769AE101

Technical Parameters

1. General Specifications:
   • Device Type: Communication/Control Module (e.g., Profibus DP Master/Slave, Ethernet/IP interface).
   • Compatibility: Designed for integration with ABB AC 800M PLCs, S800 I/O systems, or ABB Ability™ 800xA DCS.
   • Series: Part of ABB’s Advant OCS or Compact Product Range.
2. Electrical Specifications:
   • Supply Voltage: 24 V DC (±10%) or 110-240 V AC (depending on configuration).
   • Power Consumption: ≤10 W (typical).
   • Isolation: 1500 V AC (input/output isolation for noise immunity).
3. Communication Interfaces:
   • Primary Protocols:
     • PROFIBUS DP (up to 12 Mbps).
     • Modbus TCP/RTU.
     • Ethernet/IP.
   • Ports:
     • 1x RJ45 Ethernet port (10/100 Mbps).
     • 1x PROFIBUS DB9 connector.
   • Redundancy: Supports dual-redundant communication paths (if applicable).
4. Environmental Ratings:
   • Operating Temperature: -40°C to +70°C (industrial-grade).
   • Humidity: 5–95% (non-condensing).
   • Certifications: UL, CE, IEC 61131-2, IEC 61326 (EMC compliance).
5. Mechanical Design:
   • Dimensions: Approx. 150 mm x 100 mm x 40 mm (varies by housing).
   • Mounting: DIN rail or panel-mounted.
   • Housing Material: Aluminum or reinforced plastic (IP20/IP40 protection).
6. Software Integration:
   • Configuration Tools: Compatible with ABB Control Builder M or Automation Builder.
   • Firmware Updates: Field-upgradable via SD card or Ethernet.

Key Product Functions

1. PROFIBUS DP Master/Slave Operation:
   • Enables seamless integration of ABB controllers with PROFIBUS DP networks, supporting up to 124 nodes.
   • Configurable as a master (for controlling field devices) or slave (for integration into larger systems).
2. Real-Time Data Exchange:
   • Facilitates high-speed data transfer between PLCs, I/O modules, and field devices (e.g., sensors, actuators).
3. Cybersecurity Features:
   • Supports secure communication protocols (e.g., TLS, VPN) and role-based access control (RBAC) for network protection.
4. Diagnostics & Troubleshooting:
   • Built-in diagnostics via LED indicators (status, error codes) and software-based logging.
   • Supports remote monitoring and predictive maintenance.
5. Redundancy & High Availability:
   • Optional redundancy configurations (e.g., hot standby) for mission-critical applications.
6. Scalability:
   • Modular design allows expansion with additional I/O modules (e.g., analog, digital, or specialty cards).

Typical Applications

• Industrial process control (chemical, oil & gas).
• Power generation and distribution systems.
• Manufacturing automation (robotics, assembly lines).
• Water/wastewater treatment plants.
