Emerson MVME61006E-0173R Embedded Industrial Computing Module

Product Description

The Emerson MVME61006E-0173R is a high-performance embedded industrial computing module designed for real-time control and data processing in harsh industrial environments. As a key member of Emerson’s MVME (Modular Versatile Microprocessor Ensemble) series, it integrates advanced computing capabilities with robust hardware features to support critical industrial automation and control applications.

Engineered for reliability, this module excels in environments with extreme temperatures, vibration, and electrical noise—common challenges in industrial settings. It serves as a core processing unit, running real-time operating systems (RTOS) to execute control algorithms, process sensor data, and communicate with peripheral devices, ensuring seamless operation in mission-critical systems.

Product Parameters

Parameter	Specification
Product Type	Embedded Industrial Computing Module
Manufacturer	Emerson (GE Intelligent Platforms legacy, integrated into Emerson)
Processor	PowerPC e500v2 dual-core processor, 1.0 GHz
Memory	2 GB DDR3 SDRAM (ECC protected); 128 MB Flash memory
Storage	Support for CompactFlash (CF) card slot; optional 4 GB eMMC
Operating System Support	VxWorks, Linux (real-time patched)
Communication Interfaces	2x Gigabit Ethernet (IEEE 802.3); 2x RS-232/422/485 serial ports; 2x USB 2.0
Expansion Interfaces	1x PCI Express x4; 1x PMC/XMC site (for I/O expansion)
Power Supply	12 VDC ±10%, 5 A maximum; optional 24 VDC input support
Operating Temperature Range	-40°C to +70°C (-40°F to +158°F)
Vibration Resistance	10-2000 Hz, 10 g rms (operating); 20 g peak (non-operating)
Shock Resistance	50 g, 11 ms half-sine (operating); 100 g, 11 ms half-sine (non-operating)
Dimensions (L x W x H)	160 mm x 100 mm x 25 mm (6.3 in x 3.9 in x 1.0 in)
Certification	CE, UL 508, ATEX/IECEx (for hazardous areas)

Product Specifications

Physical Specifications

The MVME61006E-0173R features a compact, rugged design with dimensions of 160 mm x 100 mm x 25 mm, optimized for space-constrained industrial enclosures. Its aluminum alloy heatsink ensures efficient thermal dissipation, eliminating the need for active cooling fans—critical for dust-prone environments. The module supports standard 3U VPX or VMEbus mounting, enabling integration into existing industrial racks.

Performance Specifications

Powered by a dual-core PowerPC e500v2 processor running at 1.0 GHz, it delivers high computational throughput for real-time control tasks. The 2 GB ECC (Error-Correcting Code) DDR3 SDRAM prevents data corruption from electrical noise, while 128 MB Flash memory provides non-volatile storage for firmware and configuration data. It supports real-time operating systems like VxWorks and Linux with real-time patches, ensuring deterministic response times (<1 ms) for time-critical control loops.

Interface Specifications

Equipped with versatile connectivity, the module includes 2x Gigabit Ethernet ports for high-speed network communication (supporting Modbus TCP/IP, Ethernet/IP), 2x multi-protocol serial ports (RS-232/422/485) for legacy device integration, and 2x USB 2.0 ports for peripheral connectivity. The PCI Express x4 and PMC/XMC expansion slots allow adding specialized I/O modules (e.g., analog/digital I/O, motion control), enhancing flexibility for custom applications.

Series

The MVME61006E-0173R belongs to Emerson’s MVME series, a family of rugged embedded computing modules with a 30-year legacy in industrial automation. The MVME series is renowned for its scalability—ranging from single-core to multi-core processors—and compatibility with industry-standard form factors (VMEbus, VPX). Designed for harsh environments, the series emphasizes reliability, with features like wide temperature ranges, vibration resistance, and ECC memory, making it a staple in sectors requiring uninterrupted operation.

Features

Ruggedized Design

Built to withstand extreme conditions, it operates in -40°C to +70°C temperatures, resists 10 g rms vibration, and endures 50 g shock, making it suitable for factory floors, vehicles, and offshore platforms.

Deterministic Performance

Dual-core PowerPC processor and real-time OS support ensure deterministic control, critical for applications like motion control and process regulation where timing precision is paramount.

Flexible Expansion

PCI Express and PMC/XMC slots enable seamless integration of specialized I/O modules, adapting to diverse application needs without redesigning the core system.

Enhanced Reliability

ECC memory corrects data errors; fanless design reduces moving parts; and wide input voltage tolerance (12 VDC ±10%) minimize downtime in unstable power environments.

Secure Connectivity

Supports industrial communication protocols and optional encryption features, ensuring secure data transmission in networked industrial systems.

Function

The primary function of the MVME61006E-0173R is to serve as a central processing unit in industrial control systems. It receives data from sensors and field devices (via connected I/O modules), processes this data using preprogrammed control algorithms, and sends commands to actuators (e.g., motors, valves) to regulate industrial processes.

In real-time applications, it executes control loops continuously, adjusting outputs based on input deviations to maintain setpoints (e.g., temperature, pressure). Its networking capabilities enable integration into supervisory control systems, allowing operators to monitor status, update firmware, and troubleshoot remotely.

Use

In industrial setups, the module is installed in rugged enclosures or racks, mounted via VMEbus/VPX connectors. It is configured with application-specific software (control algorithms, communication protocols) using Emerson’s programming tools. Power is supplied via 12 VDC, with optional redundancy for critical systems.

Field devices (sensors, actuators) connect to the module directly or via expansion I/O modules. During operation, it runs 24/7, processing data and executing controls while logging diagnostics to flash memory. Maintenance involves remote monitoring via Ethernet, firmware updates over the network, and periodic checks of expansion module connections.

Application Fields

Industrial Automation

Used in factory automation for controlling production lines, robotic cells, and conveyor systems. Its deterministic performance ensures precise synchronization of multi-axis motion control in automotive assembly or electronics manufacturing.

Energy Sector

Deployed in power plants (thermal, wind, solar) to regulate turbine speed, manage grid connections, and monitor equipment health. Its ruggedness withstands high temperatures in turbine enclosures and vibration in wind turbine nacelles.

Transportation

Integrated into railway signaling systems, marine propulsion controls, and aerospace ground equipment. Supports real-time monitoring of vehicle systems, ensuring safe and efficient operation in mobile environments.

Oil and Gas

Used in offshore platforms and pipeline control systems to regulate flow rates, monitor pressure, and trigger emergency shutdowns. Resists corrosive environments and unstable power supplies common in these settings.

Medical Devices

Employed in diagnostic equipment and medical robotics, where reliable real-time processing ensures accurate measurements and precise device movement, adhering to strict safety standards.

In conclusion, the Emerson MVME61006E-0173R is a versatile embedded computing module that combines ruggedness, performance, and flexibility to power critical industrial control systems. Its integration into the MVME series ensures compatibility, reliability, and scalability, making it an ideal choice for industries demanding uninterrupted operation in harsh environments.
