GE 2400-21004 2010-3101-0442 sensor

Product Identification & Core Description

• Product Type: Reusable Blood Pressure Cuff (for 2400-21004) and NIBP Sensor/Tubing Assembly (for 2010-3101-0442).
• Series: Part of the GE Healthcare DINAMAP PRO Series or compatible CARESCAPE patient monitoring platform legacy accessories.
• Core Function: Enables Non-Invasive Blood Pressure (NIBP) monitoring on compatible GE Healthcare patient monitors.
• Typical Use: This combination is used to measure a patient’s Systolic Pressure, Diastolic Pressure, and Mean Arterial Pressure (MAP).

Product Parameters & Specifications (Representative – Based on Components)

1. Cuff (2400-21004 – Representative Example: Adult Size):
   • Cuff Size: Adult (Specific size like “Adult Long” might be implied by 21004, but exact mapping requires GE docs. Common sizes are Infant, Child, Small Adult, Adult, Large Adult, Thigh).
   • Cuff Type: Reusable, Washable.
   • Bladder Dimensions: Length and Width specific to the size (e.g., ~22-32cm circumference range for Adult).
   • Connector: Standard GE luer-lock connector for attaching to the sensor/tubing assembly.
   • Material: Typically Nylon, Dacron, or similar durable fabric. Latex-free.
   • Compatibility: Designed for use with GE DINAMAP PRO/CARESCAPE NIBP modules/sensors.
2. NIBP Sensor/Tubing Assembly (2010-3101-0442 – Representative Example):
   • Type: Reusable Disposable Blood Pressure Transducer (RDBPT) or similar NIBP sensor assembly.
   • Function: Converts pressure oscillations in the cuff into electrical signals for the monitor.
   • Tubing Length: Standard length (commonly 48 inches / 122 cm or 72 inches / 183 cm – 0442 likely denotes a specific variant/length).
   • Connectors:
     • Patient End: Luer-lock connector for attaching to the cuff (2400-21004).
     • Monitor End: Specific plug compatible with GE DINAMAP PRO/CARESCAPE NIBP ports.
   • Features: Often integrates the necessary air tubing and electrical connections in one assembly. May include features like over-pressure protection.
   • Material: Medical-grade plastics, silicone tubing. Latex-free.

Combined Key Features

• Non-Invasive: Provides essential BP data without needles or catheters.
• Compatibility: Specifically designed for integration with GE Healthcare patient monitors (e.g., DINAMAP PRO 100/200/400, CARESCAPE Bx50/Bx5x/Monitors).
• Reusable Components: Cuff is reusable; Sensor/Tubing assembly may be reusable or labeled as “Reusable Disposable” (RDBPT), meaning it can be cleaned and re-used per protocol but has a limited lifespan.
• Accuracy: Meets relevant standards (e.g., AAMI SP10, EN 1060) when used correctly with compatible monitors and properly sized cuffs.
• Safety: Latex-free materials standard. Over-pressure protection integrated.
• Ease of Use: Standardized connectors ensure quick setup.

Role & Function

• Primary Role: To safely and accurately measure a patient’s blood pressure non-invasively using the oscillometric method.
• How it Works (Simplified): The cuff inflates to occlude the artery. As it slowly deflates, the sensor detects pressure oscillations within the cuff. The monitor analyzes these oscillations to determine systolic, diastolic, and mean arterial pressures.

Purpose & Applications

• Purpose: To provide clinicians with vital hemodynamic information for patient assessment, diagnosis, treatment decisions, and monitoring during various care settings.
• Uses:
  • Routine vital sign assessment.
  • Monitoring during surgery (pre-op, intra-op, post-op).
  • Critical care monitoring (ICU, CCU).
  • Emergency department assessment.
  • Recovery room monitoring.
  • General ward monitoring.
  • Clinics and physician offices.
• Application Fields:
  • Hospitals: Operating Rooms (OR), Intensive Care Units (ICU), Critical Care Units (CCU), Emergency Departments (ED), Post-Anesthesia Care Units (PACU), General Wards.
  • Ambulatory Surgery Centers (ASCs)
  • Clinics & Physician Offices
  • Home Healthcare (Less common for this exact sensor type, but BP monitoring is key)
  • Emergency Medical Services (EMS) / Ambulances (With compatible portable monitors).
