Product Description
The GE D20MIC10BASE-T 820-0756 is an Ethernet communication interface module designed for GE’s legacy D20 Micro Programmable Logic Controller (PLC) series. It enables 10 Mbps Ethernet connectivity for industrial control networks, supporting peer-to-peer communication and remote PLC programming.
Product Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Manufacturer/Series
|
GE Industrial Systems / D20 Micro PLC Series
|
|
Part Number
|
820-0756 (Discontinued, replaced by IC220ENT101)
|
|
Interface Type
|
10BASE-T Ethernet (IEEE 802.3)
|
|
Connectors
|
2x RJ45 Ports (Auto-MDIX)
|
|
Data Rate
|
10 Mbps
|
|
Protocol Support
|
EGD (Ethernet Global Data), SRTP (Services Request Transport Protocol)
|
|
Isolation
|
1500V AC (field-to-logic)
|
|
Voltage Range
|
24V DC (19–30V DC)
|
|
Backplane Current
|
5V DC: 350 mA
|
|
Operating Temperature
|
-40°C to +85°C
|
|
Housing Material
|
Flame-retardant plastic (UL 94 V-0)
|
|
Certifications
|
UL 508, CE, FCC Part 15
|
|
Compatible PLCs
|
D20 Micro PLC CPUs (e.g., D20MIC, D20MICRO)
|
Key Features
- Dual RJ45 Ports: Daisy-chain multiple PLCs without switches.
- EGD Support: Real-time data exchange between GE PLCs/PACs.
- Non-Volatile Memory: Retains configuration during power loss.
- Diagnostic LEDs: Link/Activity, Error, Power status indicators.
- Firmware Upgradable: Via TFTP or Proficy PLC programming software.
Function & Role
- Network Integration: Connects D20 PLCs to SCADA, HMIs, or other PLCs.
- Remote Access: Enables programming/monitoring via Ethernet.
- Data Sharing: Facilitates machine-to-machine communication using EGD.
Applications & Industries
|
Industry
|
Use Cases
|
|---|---|
|
Power Generation
|
Turbine control systems, generator monitoring
|
|
Water/Wastewater
|
Pump station control, chemical dosing systems
|
|
Manufacturing
|
Legacy production line control, conveyor synchronization
|
|
Oil & Gas
|
Wellhead monitoring, pipeline valve control
|
|
Transportation
|
Tunnel ventilation control, baggage handling systems
|
Compatibility & Integration
|
System Component
|
Compatible Models
|
|---|---|
|
D20 PLC CPUs
|
D20MIC, D20MICRO
|
|
Programming Software
|
VersaPro™, Proficy Machine Edition (with D20 support)
|
|
Network Protocols
|
EGD, SRTP, Modbus TCP (via gateway)
|
|
Legacy Networks
|
Interworks with Genius Bus, Profibus via gateways
|
