GE Electric | DS200DCFBG1BNC | Field Contact Input Module
Product Description:
The GE DS200DCFBG1BNC is a Field Contact Input Module designed for GE’s Speedtronic Mark V gas/steam turbine control system. Its primary function is to interface with field devices (e.g., switches, relays, sensors) by receiving dry contact signals (open/close states), providing electrical isolation, converting inputs to digital logic levels, and transmitting status data to the Mark V controller for critical protection and control logic.
Product Parameters / Specifications (DS200DCFBG1BNC):
|
Feature
|
Specification / Description
|
|---|---|
|
Manufacturer
|
GE Energy / GE Industrial Systems
|
|
Series
|
Speedtronic Mark V Turbine Control System
|
|
Part Number
|
DS200DCFBG1BNC
|
|
Module Type
|
Digital Contact Input Module
|
|
Primary Function
|
Acquisition & Isolation of Dry Contact Field Signals
|
|
Input Signal Type
|
Dry Contact (Voltage-Free, Sink/Source)
|
|
Number of Channels
|
16 Channels (Typical Configuration)
|
|
Isolation Voltage
|
High Voltage Isolation (≥2000V AC) between Field & System
|
|
Input Voltage Range
|
Compatible with 24VDC/48VDC/125VDC Field Signals (Configurable)
|
|
Response Time
|
< 10 ms (Typical)
|
|
Redundancy Support
|
Designed for use in Redundant (Dual-Path) Mark V Systems
|
|
LED Indicators
|
Per-Channel Status LEDs (Input Active/Inactive)
|
|
Connectors
|
Screw Terminal Blocks for Field Wiring
|
|
Mounting Location
|
Installed in Mark V or Series I/O Pack
|
|
Operating Temperature
|
-40°C to +70°C (Industrial Grade)
|
Key Features:
- High-Density Inputs: 16 discrete channels per module.
- Galvanic Isolation: Protects sensitive control electronics from field-side voltage spikes/transients.
- Dry Contact Interface: Compatible with switches, relays, breaker aux contacts.
- Fast Scanning: Rapid response critical for turbine protection trips (<10ms).
- Redundancy-Ready: Supports dual-redundant Mark V configurations.
- Diagnostic LEDs: Real-time per-channel status indication.
- Robust Design: Industrial-grade components for harsh power plant environments.
- Configurable Logic: On-board processing for debounce, latching, or voting logic.
Primary Function & Purpose:
The DS200DCFBG1BNC provides secure, isolated acquisition of critical binary field signals (e.g., emergency stops, pressure switches, valve limits) into the Mark V control system. It ensures reliable digital conversion and fast transmission of these signals for turbine protection sequences, interlock logic, and operational state monitoring.
Typical Applications & Use Cases:
- Trip System Inputs: Emergency stop (ESD), overspeed detection, vibration trips.
- Status Monitoring: Breaker position (52G/52CB), valve limit switches (open/close).
- Protective Devices: Lube oil pressure low, exhaust temperature high, flame detection.
- Interlock Signals: Startup permissives, sequence step confirmations.
- Auxiliary Contacts: Pump/compressor run status, filter differential pressure.
Application Field:
This module is deployed exclusively in turbine control systems within:
- Power Generation: Gas turbine (GT), steam turbine (ST), combined-cycle (CCPP) plants.
- Industrial Drives: Compressor/pump stations using turbine drivers.
- Marine Propulsion: Naval or commercial vessel turbine engines.
It operates in the critical safety and control layer of Industrial Control Systems (ICS) for energy infrastructure, requiring SIL 2/SIL 3 compliance for protection functions.
