GE Electric | IS210BPPBH2CAA | Bus Protection and Control Module
IS210BPPBH2CAA Product Overview
Functional Description:
The GE IS210BPPBH2CAA is a Bus Protection and Control Module from GE’s Mark VIe Speedtronic™ series. It provides real-time monitoring, fault detection, and protection for electrical bus systems in power generation and industrial facilities. The module integrates with sensors, breakers, and control networks to execute protective relaying logic (e.g., differential current protection, overcurrent blocking).
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Part Number
|
IS210BPPBH2CAA
|
|
Series
|
GE Mark VIe Turbine Control System
|
|
Function
|
Bus Protection & Control Logic
|
|
Input Voltage
|
24 V DC (±10%) via backplane
|
|
Communication
|
Dual 100 Mbps Ethernet (SRTP), IEC 61850-3
|
|
I/O Channels
|
32 digital I/O, 16 analog inputs (16-bit res.)
|
|
Processor
|
PowerPC® e500 core @ 800 MHz
|
|
Operating Temp.
|
-20°C to +60°C (-4°F to +140°F)
|
|
Safety Rating
|
SIL 3 (IEC 61508)
|
|
Firmware
|
Configurable via GE ToolboxST™ (v8.0+)
|
|
Certifications
|
UL 508, CE, cULus, RoHS
|
Product Series
- Part of GE’s Mark VIe platform for distributed turbine/generator control, compatible with Speedtronic™ safety systems.
Key Features
- High-Speed Trip Logic: <5 ms response time for critical faults.
- Zone-Selective Interlocking (ZSI): Coordinates breaker trips to isolate faults.
- Cyber Hardened: Supports NERC CIP compliance with encrypted comms.
- Redundant Power Inputs: Dual 24V DC paths for fault tolerance.
- Hot-Swappable: Tool-less replacement during operation.
- Advanced Diagnostics: Predictive failure alerts via LED/software.
Functions & Roles
- Differential Current Protection: Detects internal bus faults.
- Breaker Failure Backup: Activates secondary trip paths.
- Synchrophasor Measurement: Monitors voltage/phase angles (IEEE C37.118).
- Sequence-of-Events (SOE) Logging: Timestamps faults at 1 ms resolution.
- Modbus TCP/RTU Gateway: Integrates with SCADA/DCS systems.
Applications & Use Cases
- Power Generation:
- Generator Bus Protection (Gas/Steam Plants).
- Grid Interconnection Synchronization.
- Industrial Facilities:
- Critical Process Bus Protection (Chemicals, Metals).
- Data Center Backup Power Management.
- Renewable Energy:
- Wind Farm Collector Bus Monitoring.
- Battery Storage System Control.
- Infrastructure:
- Hospital/UPS System Fault Coordination.
- Railway Electrification Substations.
Documentation & Support
- Manual: GEH-6856 (Mark VIe Protection Functions).
- Software: GE ToolboxST™ for logic configuration.
- Compatibility: Interfaces with IS200/IS215 I/O packs.
- Lifecycle: Covered under GE’s PVE793203M service plan.
- Datasheet: GE Digital Support (Search part number).
