GE Electric | IS210MACCH1AGG | Multi-Channel Analog Control Board
IS210MACCH1BGG Product Overview
Functional Description:
The GE IS210MACCH1BGG is a Multi-Channel Analog Control Board for Mark VIe turbine management systems. It processes 16-bit analog input/output signals (voltage/current) with galvanic isolation, enabling precise monitoring and control of critical parameters (pressure, temperature, flow) in power generation applications.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Part Number
|
IS210MACCH1BGG
|
|
Series
|
Mark VIe Speedtronic™ Turbine Control
|
|
Function
|
8-Channel Analog I/O Board
|
|
Input Channels
|
4x ±10V DC or 4x 0–20mA (software-selectable)
|
|
Output Channels
|
4x 0–10V DC or 4x 4–20mA (16-bit resolution)
|
|
Accuracy
|
±0.1% FSR @ 25°C
|
|
Isolation
|
1500 V RMS (channel-to-channel/logic)
|
|
Sampling Rate
|
100 Hz per channel
|
|
Communication
|
VDI Bus (to controller), 100 Mbps Ethernet (diagnostics)
|
|
Power Supply
|
+5V DC ±5%, 1.2A (via backplane)
|
|
Operating Temp.
|
-40°C to +70°C
|
|
Humidity
|
5–95% non-condensing
|
|
Compatibility
|
Mark VIe ,, or racks
|
|
Certifications
|
UL 508, IEC 61000-6-4 (EMC), SIL 2
|
Product Series
- Core component of Mark VIe I/O Pack Series (compatible with IS200/IS215 frames).
Key Features
- Auto-Calibration: Self-diagnosis of offset/gain drift via VDI bus.
- Redundant Operation: Supports dual-redundant configuration for fail-safe control.
- Diagnostic LEDs: Per-channel status (green = active, red = fault).
- HART Protocol Support: Optional field device communication (via add-on card).
- EMC Shielding: Conformal-coated PCB with aluminum housing.
- Hot-Swappable: Replaceable without system shutdown.
Functions & Roles
- Signal Conditioning: Linearization/scaling for RTDs, thermocouples, pressure transducers.
- Closed-Loop Control: PID output for valves/dampers via analog signals.
- Redundancy Management: Automatic switchover during channel failure.
- Fault Logging: Stores calibration errors/over-range events in non-volatile memory.
- Safety Shutdown: Interfaces with trip system for analog value thresholds.
Applications & Use Cases
|
Industry
|
Application
|
|---|---|
|
Power Plants
|
Gas turbine fuel valve positioning
|
|
Hydroelectric
|
Governor gate control
|
|
Refineries
|
Compressor discharge pressure control
|
|
Chemical Processing
|
Reactor temperature monitoring
|
|
District Heating
|
Steam flow regulation
|
Documentation & Support
- Manual: GEH-6850 Vol. II (Mark VIe I/O Systems)
| Software Tools | Firmware Requirements |
|————————-|—————————-|
| GE ToolboxST™ | Min. MKVIe V05.03 |
| Cimplicity™ HMI | FPGA Rev 1.6+ | - Replacement Models:
- IS210MACCH1BDG (Enhanced EMC)
- IS210MACCH1BHG (High-Temp -55°C to 85°C)
Critical Notes:
- Wiring Requirements: Shielded twisted pairs (max 500m for 4–20mA).
- Sensor Excitation: +24V @ 20mA available for transmitters (fused).
- Derating: Accuracy reduced by ±0.02%/°C beyond 25°C.
- Obsolescence: Part of legacy Mark VIe; upgrade to Mark VIeS recommended.
- VDI Bus Limit: Max 16 I/O packs per controller rack.
- Do Not Use: For intrinsically safe circuits (requires IS210BAPCH1B barrier).
