GE IC695CPE400-ABAB PACSystems RX3i series CPU module
Product Description
The IC695CPE400-ABAB is a high-performance Programmable Automation Controller (PAC) CPU module from GE’s PACSystems RX3i series. Designed for complex industrial automation, it combines robust processing power with redundant capabilities (“ABAB” suffix) for mission-critical applications. Supports mixed I/O systems and real-time deterministic control.
Product Parameters & Specifications
|
Parameter Category
|
Specification
|
|---|---|
|
Manufacturer/Series
|
GE Fanuc / PACSystems RX3i Series
|
|
Model Code
|
IC695CPE400-ABAB
|
|
Processor
|
1 GHz Dual-Core Intel® Atom™
|
|
Memory
|
20 MB User Memory
10 MB Battery-Backed RAM |
|
I/O Capacity
|
Up to 30,000 Digital Points
512 Analog Modules |
|
Scan Time
|
0.03 ms/K Boolean Instructions
|
|
Communication Ports
|
2x Embedded Ethernet (10/100 Mbps)
1x Serial RS-232/485 |
|
Protocols Supported
|
SRTP, Modbus TCP, Modbus RTU, PROFINET
EtherNet/IP, OPC UA |
|
Redundancy
|
Hot Standby (HSBY) Support (“ABAB” Suffix)
Sync via Ethernet |
|
Programming Languages
|
IEC 61131-3: LD, FBD, ST, SFC, C
|
|
Motion Control
|
4-Axis Synchronization
|
|
Operating Temperature
|
-20°C to +60°C
|
|
Power Supply
|
5V DC (via RX3i Backplane)
|
|
Certifications
|
UL, CE, cULus, RoHS, IEC 61131-2
|
|
Firmware Updates
|
Via SD Card Slot
|
Key Features
- Dual Ethernet Ports: Independent IP addresses for SCADA/PLC separation.
- Deterministic Control: ≤1 ms I/O update times for high-speed processes.
- Cyber Security: Password protection, role-based access, TLS encryption.
- Redundancy: Seamless switchover during faults (<50 ms).
- Data Logging: Integrated SQL-compatible database storage.
- Hot Swapping: Supports module replacement without shutdown.
Function & Role
- Central Control Unit: Executes logic, motion, and process algorithms.
- Data Hub: Integrates I/O networks (Profibus, DeviceNet, Genius Bus).
- Communications Gateway: Bridges legacy protocols to IIoT systems.
- Redundancy Manager: Synchronizes primary/backup CPUs for fault tolerance.
Applications & Industries
|
Industry
|
Use Cases
|
|---|---|
|
Power Generation
|
Turbine control, grid synchronization, switchgear automation
|
|
Oil & Gas
|
Pipeline SCADA, compressor control, safety shutdown systems (SIS)
|
|
Water/Wastewater
|
Pump station optimization, chemical dosing, filtration control
|
|
Manufacturing
|
Automotive assembly lines, robotic cell control, CNC machine integration
|
|
Transportation
|
Tunnel ventilation, conveyor sorting, baggage handling systems
|
|
Food & Beverage
|
Batch processing, pasteurization control, packaging line synchronization
|
Hardware Integration
- Backplane Compatibility: RX3i Universal Backplane (IC695CHSxxx).
- I/O Modules: Supports >200 IC695/IC694 series analog/digital/specialty modules.
- Expansion: Up to 16 racks via Profibus or Genius Bus.
Software Ecosystem
- Programming: Machine Edition (Proficy ME) Versions 9.0+.
- HMI Integration: Cimplicity, iFIX, Ignition SCADA.
- Cybersecurity Tools: CIP Security, VLAN segmentation.
Configuration Notes
- Redundancy Setup: Requires matched CPUs + IC695RED001 redundancy module.
- Memory Allocation: Max 2MB per task; supports up to 256 tasks.
- Real-Time Clock: ±2 minutes/month accuracy with battery backup.
- CTI Rating: 175 for industrial environments (IEC 61131-2).
