Brand: GE (General Electric), formerly GE Fanuc Automation, now owned by Emerson Automation
Model: IC754VGL06CTD ES0622
Series: QuickPanel View Series
Function: Industrial color touch screen Human-Machine Interface (HMI). It realizes real-time data display, parameter configuration, fault alarm and remote monitoring, serving as a visual operation terminal for industrial automation systems.
Voltage: Operates at 10.8-30.0V DC, adapting to various industrial power supply environments.
IC754VGL06CTD ES0622
I. Core Positioning and Overall Overview
GE IC754VGL06CTD ES0622 is a professional industrial HMI under GE QuickPanel View series.
It is a compact color touch screen terminal, designed for industrial automation and process control scenarios.
It acts as a bridge between operators and industrial control equipment, simplifying operation and monitoring.
It runs on Windows Compact Embedded (CE) operating system and is loaded with Proficy Machine Edition software.
This product is a mature industrial-grade device with stable spot supply, including rigorously tested refurbished parts.
It provides a 12-month functional warranty to ensure reliable operation in harsh industrial environments.
It is widely used in various industrial fields, offering intuitive and efficient human-machine interaction.
II. Core Technical Specifications
All parameters meet GE industrial standards. They ensure stable operation in harsh industrial on-site conditions.
The core technical specifications are as follows:
1. Basic Parameters
-
Product Model: IC754VGL06CTD ES0622
-
Manufacturer: GE (formerly GE Fanuc Automation, now Emerson Automation)
-
Product Type: Industrial color touch screen HMI (Human-Machine Interface)
-
Display: 6-inch TFT color LCD, 65,536 colors, resolution of 320 x 240 pixels
-
Processor: Intel XScale PXA300 processor, clock frequency of 255 MHz
-
Memory: 64 MB flash memory, 512 KB SRAM, 64 MB DRAM, 512 KB bootloader
-
Mounting Type: Panel mount, suitable for industrial control cabinet installation
-
Origin: USA
2. Electrical Parameters
-
Operating Voltage: 10.8-30.0V DC
-
Power Supply Mode: DC power supply via quick connect plug
-
Touch Screen: Analog resistive touch screen, supporting flexible operation
-
Bezel Material: Valox 357U, durable and suitable for industrial environments
3. Communication and Interface Parameters
-
Communication Interfaces: 2 Ethernet interfaces, 1 serial combo port (supports EIA232C/EIA485), 2 USB interfaces
-
Ethernet Speed: 10/100 Mbps, supporting long-distance data transmission
-
Communication Protocols: Compatible with mainstream industrial communication protocols, supporting point-to-point and networked communication
-
Data Transmission: Supports application download via Ethernet, ensuring efficient configuration
4. Software and Function Parameters
-
Operating System: Windows Compact Embedded (CE) operating system
-
Software Support: Loaded with Proficy Machine Edition software for application development and configuration
-
Display Function: Can display graphics, curves, tables, and real-time equipment status
-
Configuration: Supports third-party application installation and custom configuration
-
Fault Alarm: Has real-time alarm display function, facilitating quick fault handling
5. Environmental Adaptability
-
Operating Temperature: 0°C to 60°C, adapting to common industrial working conditions
-
Storage Temperature: -40°C to 85°C, humidity 10%~95%RH (non-condensing)
-
Reliability: High MTBF (Mean Time Between Failures), ensuring long-term stable operation
-
Anti-interference Capability: Strong anti-electromagnetic interference, resisting industrial site noise
-
Protection Level: Suitable for installation in industrial control cabinets, with good dust and moisture resistance
IC754VGL06CTD ES0622
III. Core Functions and Advantages
1. Intuitive Visual Operation
It has a 6-inch color display with 65,536 colors. It shows real-time data and equipment status clearly.
The analog resistive touch screen supports flexible operation, simplifying operator interaction.
2. Powerful Communication Capability
It is equipped with multiple communication interfaces. It supports Ethernet, serial and USB communication.
It can connect with PLC,变频器 and other control equipment, realizing seamless data exchange.
3. Flexible Configuration and Expansion
It runs on Windows CE system and supports third-party application installation.
It can be custom-configured according to on-site needs, adapting to different industrial scenarios.
4. Easy Installation and Maintenance
It adopts panel mount design, which is easy to install and disassemble.
Applications can be downloaded via Ethernet, simplifying configuration and maintenance processes.
5. Industrial-Grade Stability
It uses high-quality industrial components and durable bezel material. It has strong environmental adaptability.
It can operate stably in harsh industrial environments, reducing downtime and maintenance costs.
IC754VGL06CTD ES0622
IV. Application Scenarios
GE IC754VGL06CTD ES0622 is widely used in industrial automation and process control. Its main applications include:
-
Power Generation: As a visual terminal in power plants, monitoring generator sets and auxiliary equipment.
-
Manufacturing Industry: Used in production lines to display and control equipment operation status.
-
Oil & Gas: Applied in oil and gas fields to monitor and control pumps, compressors and other equipment.
-
Water and Wastewater Treatment: Monitoring and controlling pumping stations and water treatment equipment.
-
Chemical Industry: Real-time display of reaction parameters, facilitating remote adjustment and control.
V. Product Summary
GE IC754VGL06CTD ES0622 is a high-performance color touch screen HMI of the QuickPanel View series.
It integrates intuitive display, flexible operation, powerful communication and reliable stability.
With 10.8-30.0V DC operating voltage, it is fully compatible with various industrial control systems.
It simplifies human-machine interaction, improves operation efficiency, and ensures stable system operation.
As a mature industrial device, it has stable spot supply and perfect quality assurance.
It is an ideal choice for retrofitting and new installation of industrial automation human-machine interface systems.
