GE IS200AEADH4ADA – Analog Input Terminal Board
Product Description: The GE IS200AEADH4ADA is a critical component within the Mark VIe series of Speedtronic turbine control systems from GE. It functions as a High-Density Analog Input Terminal Board. Its primary role is to acquire multiple low-voltage analog DC signals (like those from sensors – temperature via RTDs/TCs, pressure, flow, position, etc.) from the field, condition them, digitize them, and transmit the data to the system’s central controller for monitoring, control sequences, and protective actions.
Product Parameters & Specifications (Typical):
|
Parameter Category
|
Specification
|
Notes
|
|---|---|---|
|
GE Model Number
|
IS200AEADH4ADA
|
Part of Mark VIe I/O Pack
|
|
Series
|
Mark VIe Speedtronic
|
GE’s Turbine/Plant Control Platform
|
|
Module Type
|
High-Density Analog Input Terminal Board
|
Installs in an I/O Pack slot
|
|
Primary Function
|
Analog Signal Acquisition & Digitization
|
For monitoring & control
|
|
Signal Type
|
Low-Level Analog DC Voltage Inputs
|
Typically mV or V range
|
|
Input Channels
|
Typically 16 channels
|
High-density configuration
|
|
Input Range
|
Programmable (e.g., ±10V, ±5V, ±1V, 0-10V, etc.)
|
Configured per application need
|
|
Resolution
|
16-bit minimum
|
High-precision conversion
|
|
Scan Rate
|
Configurable (e.g., per group, typical rates apply)
|
Depends on system load & config
|
|
Accuracy
|
High Accuracy (Specific % of reading or range, e.g., ±0.1%)
|
Refer to detailed datasheet
|
|
Isolation
|
Channel-to-Channel & Channel-to-Bus Isolation
|
Critical for noise immunity & safety
|
|
Isolation Voltage
|
Typically 1500 VAC or higher
|
Protects system & field wiring
|
|
Termination
|
Spring-clamp or screw terminal blocks
|
On-board for field wiring
|
|
HART Support
|
ADA suffix denotes HART protocol capability
|
Key Feature: Allows digital communication over analog wires
|
|
Protocol/Interface
|
Communicates via VME backplane to controller (VMIC)
|
Uses Mark VIe backplane
|
|
Power Supply
|
Derived from I/O Pack backplane (+5V, +3.3V, etc.)
|
No external power required
|
|
Operating Temp.
|
Standard Industrial Range (e.g., 0°C to +60°C)
|
|
|
Certifications
|
Designed to meet relevant industrial & safety standards (e.g., UL, CE, ATEX for specific assemblies)
|
System level dependent
|
Note: The table above lists typical specifications. Exact values (accuracy, scan rates, etc.) depend on the specific hardware revision, firmware, and system configuration. Always consult the official GEH-6855 Mark VIe Systems Guide or specific module datasheet for definitive parameters.
Key Features:
- High Channel Density: Reduces footprint and cost per point.
- High Resolution & Accuracy: Ensures precise measurement of critical process variables.
- Programmable Ranges: Flexible configuration for various sensor types and signal levels.
- Robust Isolation: Essential for noise rejection, signal integrity, and safety in harsh industrial environments.
- HART Protocol Support (ADA suffix): Critical Feature: Enables two-way digital communication with HART-enabled smart field devices (transmitters, positioners) over the standard 4-20mA analog wiring. Allows for device configuration, diagnostics, and multivariable data access without separate wiring.
- Designed for Reliability: Built to withstand industrial environments (temp, vibration, EMI).
- Hot-Swappable (System Dependent): Often designed to be replaceable while the system is powered (within Mark VIe safety protocols).
- Integrated Termination: Simplifies field wiring connection.
- Compatibility: Seamless integration within the Mark VIe controller architecture and ToolboxST engineering tools.
Function & Role: The IS200AEADH4ADA acts as the interface between low-level analog field sensors/devices and the Mark VIe controller. It:
- Acquires analog voltage signals.
- Conditions signals (filtering, isolation).
- Digitizes the analog signals using high-resolution A/D converters.
- Supports HART communication multiplexed on analog channels.
- Transmits the digital data (and HART data) to the Mark VIe controller via the VME backplane.
- Provides electrical isolation between field wiring and the sensitive control system electronics.
Purpose & Primary Uses:
- To monitor critical process parameters (temperature, pressure, flow, level, vibration, position, etc.) in real-time.
- To provide high-fidelity input data for the control system’s logic, algorithms, and protective functions.
- To enable closed-loop control by providing feedback signals.
- To diagnose process or equipment issues based on sensor readings.
- To interface with HART smart devices for configuration, calibration, and advanced diagnostics without disrupting the 4-20mA signal.
Application Fields: The IS200AEADH4ADA is primarily used in industries requiring high-reliability, distributed control for critical rotating equipment and processes, particularly:
- Power Generation:
- Gas Turbine Power Plants (Simple Cycle & Combined Cycle)
- Steam Turbine Power Plants
- Hydroelectric Plants
- Distributed Power (Aero-derivative Gas Turbines)
- Balance of Plant (BOP) monitoring & control
- Oil & Gas:
- Gas Compression Stations (Pipeline)
- Oil & Gas Production Platforms (Onshore/Offshore)
- LNG Liquefaction & Regasification Facilities
- Refineries (Process monitoring)
- Industrial Processing:
- Chemical Plants
- Petrochemical Plants
- Pulp & Paper Mills
- Metal Processing
- Water & Wastewater Treatment Plants
- Marine:
- Propulsion control and monitoring for ships using gas turbines or diesel engines.
