Name: IS200JPDDG1AAA GE RST I/O board
SKU: 7933
Price: 1460.00 USD
Availability: InStock

GE IS200JPDDG1AAA is an analog RST I/O board belonging to the Mark V series, specifically engineered for gas turbine control systems. It excels at scaling and conditioning a wide array of analog signals read by terminal boards on the I/O cores R1, R2, and R3, covering LVDT inputs, thermocouple inputs, 4 – 20 mA signals (such as compressor surge detection and fuel flow pressure signals), vibration inputs, and generator line signals. It communicates and transmits signals with other boards via dedicated connectors — some signals are sent to the STCA board through the 3PL connector, while the JE connector enables the sending and receiving of generator and line signals with the TCQC board. Equipped with hardware jumpers for configuring current output ranges and card testing, this rugged module ensures reliable performance in industrial settings like power generation, and is pivotal for the stable operation of gas turbine control systems by optimizing signal processing and transmission efficiency.

STAI INSTALLATION:

A sheet metal carrier that is mounted on a DIN rail carries the STAI together with a plastic insulator. The STAI plus insulator can alternatively mount to a sheet metal assembly before being fastened directly to a cabinet. There are two different varieties of Euro-block terminal blocks available:

A permanently mounted terminal block with 48 terminals is present on STAI 1.
A right-angle header on STAI 2 accepts a variety of pluggable terminal blocks that are readily accessible and have a total of 48 terminals.
Typically, shielded twisted pair (#18 AWG) wires are utilized. There is an I/O cable shield terminal available next to the terminal blocks.

It is possible to accept the following analog input and output types:
