General Electric IS200TDBTH6ABC is a discrete simplex board belonging to the Mark VI Speedtronic series, specifically designed for steam and gas turbine control systems. It is equipped with twelve black potentiometers arranged in three horizontal rows of four, flanked by rectangular gray components, along with red metal oxide varistors, a small yellow capacitor and resistors, forming a well-structured hardware layout. The board has a conformal PCB coating for enhanced durability and can be DIN rail-mounted for easy installation. It mainly processes and transmits key signals for turbine operation, and its rugged design and reliable component configuration enable it to maintain stable performance in harsh industrial environments, playing a crucial role in ensuring the safe and efficient operation of turbine systems in power generation and other heavy industries.
STAI INSTALLATION:
A sheet metal carrier that is mounted on a DIN rail carries the STAI together with a plastic insulator. The STAI plus insulator can alternatively mount to a sheet metal assembly before being fastened directly to a cabinet. There are two different varieties of Euro-block terminal blocks available:
- A permanently mounted terminal block with 48 terminals is present on STAI 1.
- A right-angle header on STAI 2 accepts a variety of pluggable terminal blocks that are readily accessible and have a total of 48 terminals.
- Typically, shielded twisted pair (#18 AWG) wires are utilized. There is an I/O cable shield terminal available next to the terminal blocks.
It is possible to accept the following analog input and output types:
- Two-wire transmitter with analog input.
- Three-wire transmitter with analog input.
- Four-wire transmitter with analog input.
- An externally powered transmitter with an analog input.
- Analog input, 5 and 10 volts direct current.
- 0-20 mA current analog output.
- Analog output, current of 0-200 mA.
