GE IS420UCSBH3A Mark VIe Series Utility Controller module
GE IS420UCSBH3A – Product Overview
The GE IS420UCSBH3A is a Mark VIe Series Utility Controller module engineered for critical turbine and rotating equipment control in industrial applications. Part of GE’s Speedtronic™ family, this high-reliability controller executes safety-rated protection logic (SIL 3 certified) and process algorithms for gas/steam turbines, compressors, and generators in demanding environments.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Manufacturer Part No.
|
IS420UCSBH3A
|
|
Product Type
|
Mark VIe Utility Controller (Single)
|
|
Series/Platform
|
GE Mark VIe Turbine Control System
|
|
Processor
|
PowerPC-based @ 400 MHz
|
|
Memory
|
128 MB SDRAM, 64 MB Flash
|
|
I/O Connectivity
|
• 3x Ethernet Ports (10/100BASE-TX RJ45)
• 1x RS-232 Serial Port |
|
Control Network
|
Triple Modular Redundant (TMR) Ethernet support
|
|
Safety Rating
|
SIL 3 (IEC 61508), TÜV-certified
|
|
Operating Temperature
|
-40°C to +70°C
|
|
Voltage Input
|
18-32 VDC (Nominal 24VDC)
|
|
Power Consumption
|
15W (Typical @ 24VDC)
|
|
Redundancy Support
|
Hardware-based TMR configuration
|
|
Certifications
|
ATEX, IECEx, UL Class I Div 2, CE, RoHS
|
|
Firmware
|
ToolboxST™ v6.0+
|
|
MTBF
|
>250,000 hours
|
Series & Family
- Series: Mark VIe Safety Programmable Controllers (SPC)
- Family: Speedtronic™ Turbine Control System
- Compatible Systems: Mark VIe, Mark VIeS
- Related Controllers: IS420UCSCH1A (Enhanced), IS420UCSBG1A (Legacy)
Key Features
- Triple Modular Redundancy (TMR): 3-channel fault-tolerant architecture
- Deterministic Execution: <1ms control loop cycle time
- Integrated Safety Logic Solver: SIL 3-compliant safety functions
- Secure Communications: AES-128 encryption for network traffic
- Hot-Swap Capability: Field-replaceable without process shutdown
- Harmonic Immunity: >100 dB noise rejection (IEEE 472)
- Built-in Diagnostics: Continuous hardware/software health monitoring
Function & Role
- Critical Machinery Protection: Overspeed detection, vibration shutdown
- Sequence Control: Automated start-up/shutdown sequencing
- Process Regulation: Fuel/air ratio control, temperature limiting
- Data Acquisition: High-speed sampling (1kHz) for condition monitoring
- Network Gateway: Interfaces with HMI/SCADA via Modbus TCP or OPC UA
Primary Applications
- Gas/Steam Turbine Governing
- Compressor Anti-Surge Control
- Generator Excitation Systems
- BOP (Balance of Plant) Automation
- Fire & Gas Safety Shutdown Systems
Application Fields
|
Industry
|
Use Cases
|
|---|---|
|
Power Generation
|
Combined-cycle plants, peaker turbines, cogeneration
|
|
Oil & Gas
|
Pipeline compressors, offshore platform power gen, LNG liquefaction
|
|
Petrochemical
|
Turbine-driven pumps/compressors, flare control
|
|
Marine
|
Ship propulsion control, auxiliary power management
|
|
Industrial
|
Drive turbines for mills, fans, blowers
|
