GE IS420UCSCH1A Controller and Ethernet Switch Module
GE IS420UCSCH1A – Product Overview
The GE IS420UCSCH1A is a Controller and Ethernet Switch Module from GE’s PACSystems RX3i series, serving as a critical control and communication hub in industrial automation systems. This ruggedized module combines a high-performance processor with industrial-grade Ethernet switching capabilities, designed for real-time control and data exchange in mission-critical applications.
Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Manufacturer
|
GE Intelligent Platforms (Now part of Emerson Electric)
|
|
Part Number
|
|
|
Series/Platform
|
PACSystems RX3i
|
|
Function
|
Dual Controller + Managed Ethernet Switch
|
|
Processor
|
800 MHz PowerPC
|
|
Memory
|
512 MB DDR2 SDRAM
|
|
Ethernet Ports
|
6 x 10/100 Mbps RJ-45 (Auto-MDI/MDIX)
|
|
Switch Features
|
• IGMP Snooping v1/v2/v3
• VLAN (802.1Q) • QoS (802.1p) |
|
Backplane Interface
|
PCI Express
|
|
Redundancy Support
|
Hot standby controller redundancy
|
|
Protocol Support
|
• Modbus TCP/IP
• SRTP • DNP3 • OPC UA |
|
Operating Temperature
|
-40°C to +70°C (-40°F to 158°F)
|
|
Shock Resistance
|
30g peak (11ms half-sine)
|
|
Vibration Immunity
|
5g (10-500 Hz)
|
|
Certifications
|
UL/cUL, CE, ATEX/IECEx Zone 2
|
|
Power Consumption
|
12W typical (24V DC)
|
|
Input Voltage
|
19-30V DC
|
|
MTBF
|
>250,000 hours (28.5 years)
|
Product Family & Series
- Primary Series: PACSystems RX3i
- Related Controllers:
- IS420UCSCH2A (Enhanced version)
- IC695CPE310 (Entry-level CPU)
- IC694PWR331 (Power supply module)
- Compatible I/O:
- VersaMax I/O modules
- RX3i Genius I/O blocks
- Chassis Compatibility: Universal Backplane (IC694CHSxxx series)
Key Features
- Integrated Control + Switching: Combines PLC functionality with Layer 2 managed switching
- Deterministic Performance: ≤1ms control loop execution time
- Cyber Security: TPM 2.0 hardware encryption, role-based access control
- Seamless Redundancy: <50ms switchover time for fault-tolerant systems
- Industrial Protocol Support: Native implementation of IEC 61850 GOOSE
- Harsh Environment Rated: Conforms to IEEE 1613 (power substations)
- Profinet IRT Class B Support: For motion control applications
Functions & Roles
- Central Processing Unit: Executes control logic for complex automation
- Network Aggregation: Connects I/O drops via integrated switch
- Data Concentrator: Collects and processes field device data
- Protocol Gateway: Translates between Modbus TCP, Profinet, and DNP3
- Edge Computing Node: Supports embedded C/C++ applications
Primary Applications
|
Industry
|
Typical Use Cases
|
|---|---|
|
Power Generation
|
• Turbine control systems
• Substation automation (IEC 61850) |
|
Oil & Gas
|
• Pipeline SCADA
• Compressor station control |
|
Water/Wastewater
|
• Pump station automation
• Chemical dosing control |
|
Manufacturing
|
• High-speed packaging lines
• Batch process control |
|
Transportation
|
• Tunnel ventilation control
• Bridge monitoring systems |
|
Renewable Energy
|
• Wind farm controller
• Solar plant management |
