GE MMII-PD-1-2-120 Product Introduction
1. Product Overview
The GE MMII-PD-1-2-120 is a reliable industrial power distribution module in GE’s MMII (Modular Motor Interface II) Series, engineered to supply stable AC power to automation components. It serves manufacturing, automotive, and process industries, focusing on powering motor controls, sensors, and small-scale actuators in distributed control systems (DCS) or programmable logic controller (PLC) networks.
Integrating overload protection and compact design, it ensures safe, efficient power distribution while fitting into space-constrained control cabinets. Compatibility with GE’s MMII series modules enables seamless system expansion, making it a practical choice for standardized industrial power management.
2. Technical Parameters (Table)
|
Category
|
Specification
|
|
Device Type
|
Industrial AC power distribution module (single-phase)
|
|
Input Voltage
|
120 V AC (single-phase); Voltage range: 90–132 V AC; Frequency: 50/60 Hz
|
|
Output Channels
|
2 independent output channels (isolated between channels)
|
|
Output Rating
|
10 A per channel (continuous); 15 A per channel (pulsed, ≤10s)
|
|
Protection Features
|
Overcurrent protection (thermal-magnetic, 10 A trip current per channel); Short circuit protection; Overvoltage protection (140 V AC max)
|
|
Efficiency
|
≥95% (at full load, 120 V AC, 60 Hz)
|
|
Power Consumption
|
≤3 W (no-load); ≤15 W (full load)
|
|
Environmental Ratings
|
Operating temperature: 0°C to +50°C (32°F to +122°F); Storage temperature: -20°C to +70°C (-4°F to +158°F); Humidity: 5%–95% (non-condensing); Protection class: IP20 (enclosure)
|
|
Mechanical Design
|
Mounting: DIN rail (35 mm); Housing material: Polycarbonate; Dimensions: 45 mm (W) × 120 mm (H) × 90 mm (D); Weight: ~300 g (0.66 lbs)
|
|
Certifications
|
CE; UL 508; CSA C22.2 No. 14; IEC 60947-4-1; RoHS compliant
|
3. Product Specifications & Features
3.1 Core Specifications
The GE MMII-PD-1-2-120 is optimized for single-phase 120 V AC power distribution, with 2 independent channels (10 A continuous each) fitting small-scale automation needs (e.g., powering 2 motor starters or 4–6 sensors). Its 90–132 V AC input range tolerates voltage fluctuations common in industrial grids, ensuring stable output for sensitive components.
Thermal-magnetic overcurrent protection prevents damage from overloads (e.g., shorted sensors), while channel isolation eliminates cross-interference between connected devices. The DIN rail mounting design simplifies installation in standard control cabinets, reducing setup time.
3.2 Key Features
- Dual-Channel Isolation: Independent outputs with isolation prevent signal interference, ensuring stable operation of connected components.
- Flexible Load Handling: 10 A continuous/15 A pulsed output supports both steady-state loads (e.g., sensors) and temporary high-current devices (e.g., actuator startup).
- Reliable Protection: Overcurrent/short circuit protection minimizes downtime from electrical faults, extending component lifespan.
- Space-Saving Design: Compact DIN rail form factor fits into dense control cabinets, optimizing space usage.
- Easy Integration: Compatibility with GE MMII series modules (e.g., MMII-PD-1-4-120) enables scalable power distribution networks.
4. Other GE Power Distribution Products
GE offers complementary power modules for diverse industrial needs:
- GE MMII-PD-1-4-120: 4-output channel variant (120 V AC, 10 A/channel) for larger-scale power distribution (e.g., multi-sensor networks).
- GE MMII-PD-3-2-240: 3-phase input module (240 V AC, 2 outputs) for powering heavy-duty motor controls (e.g., conveyor drives).
- GE MDS-PD-1-2-24: DC power distribution module (24 V DC, 2 outputs) for low-voltage components (e.g., PLC I/O modules).
- GE MMII-PD-1-2-230: 230 V AC input variant (2 outputs) for European/global industrial grids.
- GE DPF Series: High-power distribution modules (up to 50 A) for heavy-industry applications (e.g., automotive assembly lines).
